High-tech Hydraulic CNC Slitter and Folder Machine For 0.3 - 1.5mm Thickness

High-tech Hydraulic CNC Slitter and Folder Machine For 0.3 - 1.5mm Thickness

Sheet Metal Roll Forming Machines

Roll Forming Equipment

Place of Origin:

China

Brand Name:

TECHWELL

Certification:

CE, BV

Model Number:

TW-CNCFDM

Contact Us

Request A Quote
Product Details
Max. Folding Thickness:
0.3-1.5mm Galvanized Steel Sheet
Max. Folding Length:
4, 6, 8, 10, 12m
Max. Folding Angle:
125 Degree
Weight Of Machine:
About 11Ton
Shearing Mode:
Rotary Slitter
Shearing Speed:
About 800mm/sec
Product Description

High-tech Hydraulic CNC Slitter and Folder Machine For 0.3 - 1.5mm Thickness





  Summary



This CNC Slitter and Folder Machine adopts CNC controller which can help to fix, clamp, fold and slit the sheet, it is a high-tech product which integrated with electromechanical and hydraulic.

The machine mainly consists of machine body, clamp unit, folding system, CNC control backstop, width shearing system, work piece supporting system, hydraulic system and PLC Control system, etc.





  Main Specifications

  • Max. folding thickness: 0.3-1.5mm Galvanized steel sheet or color steel sheet; 2.0mm Max. for Aluminium
  • Max. folding length: 4, 6, 8, 10, 12m
  • Max. folding angle: 125 degree
  • Weight of machine: about 11Ton
  • Width slitting function
  • Max. shearing thickness: 0.3-1.5mm Galvanized steel sheet or color steel sheet; 2.0mm Max. for Aluminium
  • Shearing speed: about 800mm/sec.
  • Shearing Mode: Rotary slitter
  • Control System: PC with 12” LCD
  • Electric Condition: 380/3Phase/50Hz ( or depend on customer’s requirement )
  • Outline dimension of main machine: 4595x1842x1375mm (LXWXH)



  Main Components

  • Machine Base
  • Clamp Unit
  • Folding Equipment
  • CNC Control
  • Width Shearing System
  • Work Piece supporting device
  • Hydraulic System
  • PLC Control System



  Our Advantages

  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience



High-tech Hydraulic CNC Slitter and Folder Machine For 0.3 - 1.5mm Thickness 0
