Quick Interchangeable C / Z Purlin Roll Forming Machine With 17 Forming Stations

China Quick Interchangeable C / Z Purlin Roll Forming Machine With 17 Forming Stations supplier

Large Image :  Quick Interchangeable C / Z Purlin Roll Forming Machine With 17 Forming Stations

Product Details:

Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-CZ300

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Detailed Product Description
Raw Material: Galvanized Steel Sheet Roller Material: GCr15 Steel, Quenched And Heated Process
Forming Station: About 17 Principle Axis: 80mm Diameter
Main Power: 18 KW Electrical Control: PLC Frequency Control System With Touch Screen

Quick Interchangeable C / Z Purlin Roll Forming Machine With 17 Forming Stations



   Main Specifications of C / Z Purlin Roll Forming Machine





  • Material: G.i Coil or Carbon steel
  • Material Thickness:1.5-3.0mm
  • Landscape orientation adjustment range of Hole distance : 45-500mm
  • Length of purlin: >3m
  • Forming Stations: about 17 Main rollers
  • Leveling Stations: 7
  • Feeding Stations: 2
  • Main Power: 20KW
  • Machine Diameter: about 12000mm(L)x2300mm(W)x1600mm(H) ( including main motor )
  • Weight of machine: about 18.5 Ton



 1. One machine can produce differenct C/Z Purlins throught simple manual stepless adjustment, when to produce different profiles, no need to change the forming rollers. In the process, machine adopt automactic control model, it can auto pumch, cut, forming based on inputting length of purlin, portrait hole distance, quantity, etc datas.



 2. C/Z purlin roll former make up of decoiler, feeding, leveling, 2 sets hydraulic punching device, hydraulic cutting, speediness interchangeable forming machine, PLC control system, hydraulic stations, runout tables.



 3. It is quick and easy to operate the machine, and beautiful appearance, high production efficiency, forming speed up to 20m/min.





   Main Components



  • Decoiler ------------------------------------------------- 1 Unit
  • Feeding & Leveling ----------------------------------- 1 Unit
  • Hydraulic punching device -------------------------- 1 Unit
  • Hydraulic cutting device ------------------------------ 1 Unit
  • Main roll forming machine ---------------------------- 1 Unit
  • Hydraulic Station --------------------------------------- 1 Unit
  • PLC computer control -------------------------------- 1 Unit
  • Output table -------------------------------------------- 1 Unit



   Reference Drawing





Quick Interchangeable C / Z Purlin Roll Forming Machine With 17 Forming Stations

Quick Interchangeable C / Z Purlin Roll Forming Machine With 17 Forming Stations





   Our Advantage





  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience







  Machine Picture





Quick Interchangeable C / Z Purlin Roll Forming Machine With 17 Forming Stations
