TW-65-400 Bemo Roof Panel Roll Forming Machine With 0 - 15m/min Speed

TW-65-400 Bemo Roof Panel Roll Forming Machine With 0 - 15m/min Speed

metal roof roll forming machine

Roof Sheet Roll Forming Machine

Place of Origin:

China

Brand Name:

TECHWELL

Certification:

CE

Model Number:

TW-STM400

Contact Us

Request A Quote
Product Details
Profile Shape:
Bemo Roof Panel
Material:
Aluminium, PPGI
Material Thickness:
0.4-0.8mm
Forming Speed:
0-20 M/min
Forming Stations:
13
Shaft Diameter:
76mm
Product Description


Bemo Roof Panel Roll Forming Machine Rolling for Making for High quailty Roof Panel Sheet

   A). Main Technical Specifications of Bemo Roof Panel Roll Forming Machine



 Item  Bemo Roof Panel Roll Forming Machine
 Coil Material                                        Thickness  0.3-0.8mm
 Coil width  Custom-made
 Yield Strength             250-350 Mpa
 Material  PPGI, Color Steel, GI. Aluminium
 Decoiler / Uncoiler  Decoiler Type  Manual or Hydraulic or Auto Type
 Coil Width  Max. 1250mm
 I.D  508-610mm
 O.D  Max. 1500mm
 Bemo Roof Panel Roll Forming Machine  Forming Stations  13 Stations ( Depend on Profiles )
 Roller material   45# steel, surface coated with 0.05mm hard  chrome
 Diameter of shaft   76mm
 Shaft material  High grade 45# steel
 Drive type  Chain transmission
 Forming speed  0-15m/min
 Main power  5.5KW
 Cutting System                                                  Cutting type  Hydraulic cutting
 Cutting Die Material  Cr12Mov steel, HRC58-62
 Cutting power  3KW
 CuttingTolerance  10m+/-1.5mm
 Encoder  OMRON Brand
 Electrical Control Board  PLC                                    PANASONIC Brand
 Inverter  YASKAWA Brand
 Touch screen  PANASONICE
 Operation type  Touch screen & Button
 Hydraulic Station  Hydraulic station  Famous Chinese brand
 Runout Tables  Table type  Simple nonpower type
 Function  To support the finished panels



   B). Main Components of Bemo Roof Panel Roll Forming Machine



 Decoiler / Uncoiler  1 Unit
 Feeding Guide  1 Unit
 Main Bemo Roof Panel Roll Forming Machine  1 Unit
 Hydraulic Cutting Device                                          1 Unit
 Hydraulic Station  1 Unit
 PLC Computer Control Board  1 Unit
 Runout Tables  2 Units



   C). Flow Chart of Bemo Roof Panel Roll Forming Machine


Decoiler ---> Fedding Guide ---> Roll Forming ---> Cut-to-length ---> Run out table

TW-65-400 Bemo Roof Panel Roll Forming Machine With 0 - 15m/min Speed 0



   D). Main Technical Specifications of Bemo Roof Panel Roll Forming Machine



TW-65-400 Bemo Roof Panel Roll Forming Machine With 0 - 15m/min Speed 1

TW-65-400 Bemo Roof Panel Roll Forming Machine With 0 - 15m/min Speed 2

TW-65-400 Bemo Roof Panel Roll Forming Machine With 0 - 15m/min Speed 3





   E). Reference Pictures of Bemo Roof Panel Roll Forming Machine



TW-65-400 Bemo Roof Panel Roll Forming Machine With 0 - 15m/min Speed 4

TW-65-400 Bemo Roof Panel Roll Forming Machine With 0 - 15m/min Speed 5



   F). Contact Methods of Bemo Roof Panel Roll Forming Machine



 Company  Wuxi Techwell Machinery Co.,LTD
 Website  www.cold-rollformingmachine.com
 www.roofrollformingmachine.com
 www.wxtechwell.com
 Video  www.youtube.com/wxtechwell
 Tel / Fax  0086-510-83133431
 Mobile / Whatsapp / Viber                0086-18018304331 ( Miss Lee )
 E-Mail  monica@wxtechwell.com
 Skype  monica198614





   G). FAQ



1)Q: What is the Warranty Machine ?
A: For our roll forming machine , we have 1 year warranty. If any quality problems in this period ,we will take on the shipping cost and replacement.


2)Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available across the world. We need your machines running in order to keep your business running.


3) Q: How do your machines compare with other big companies in this market?
A: We are up to date with the latest technology and improve our machines accordingly


4)Q: How does your factory do regarding quality control?
A: Quality is priority. We always attach great importance to quality control from the very
beginning to the end of the production. Every product will be fully assembled and carefully tested before it's packed for shipment.


5) Q: Do you sell only standard machines?
A: No, most of our machines are built according to customers specifications, using top brand name components.


6) Q: Will you deliver the right goods as ordered? How can I trust you?
A: Yes, we will. The core of our company culture is honesty and credit. We have good reputation in this field for ten years' experience.
