K Span Roof Panel Roll Forming Machine For Coil Width 914mm , 17.7kw Capacity Large Power

China K Span Roof Panel Roll Forming Machine For Coil Width 914mm , 17.7kw Capacity Large Power supplier

Large Image :  K Span Roof Panel Roll Forming Machine For Coil Width 914mm , 17.7kw Capacity Large Power

Product Details:

Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-K610

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Contact us
Packaging Details: Standard packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20sets
Detailed Product Description
Thickness Of Sheet: 0.8-1.2mm Coil Width: 914mm
Total Weight: About 13T Main Motor Power: 17.7Kw
Forming Power: 7.5Kw Curving Motor Power: 4 Kw

K Span Roof Panel Roll Forming Machine For Coil Width 914mm, 17.7kw Capacity Power





   Descriptions





 1. The structure is simple and the appearance of the machine is beautiful because we adopt the shape-steel structure and process as a whole after welding.



 2. It has the ability of strong loading and stable operation when running the machine.



 3. All the components of machine are from brand-famous enterprise so that they ensure the machine normal function very effectively.



 4. We adopt the automatic length-fixed forming and cutting to guarantee the length to be precise and the finished product clear without deforming .



   Main Specifications of K Span Roof Panel



1. Material of the profile: G.i or Cabon steel

2. Thickness of sheet: 0.8-1.2mm

3. Coil width: 914mm

4. Effective width: 610mm

5. Mounting dimension: 8900mmx2250mmx2300mm

6. Total weight: about 13 Ton

7. Control system: electric control

8. Main motor power: 17.7KW

9. Forming Power is 7.5KW

10. Curving motor power: 4KW

11. Electric cutting motor power: 4kw

12. Conical Power is 2.2KW

13. Material of rollers: 45# steel, quenched HRC58-62

14. Material of shaft: 45# steel, adjusted

15. Material of cutting blade: Cr12 steel

16. Quenching hardness: HRC58-60

17. Forming Stations: 13 steps





   Profile Drawing



K Span Roof Panel Roll Forming Machine For Coil Width 914mm , 17.7kw Capacity Large Power





   Working Flow



Decoiling—feeding—roll forming—-cut to length—product packing manual—arching—seaming





   Finished Products



K Span Roof Panel Roll Forming Machine For Coil Width 914mm , 17.7kw Capacity Large Power





   Our Advantages



  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience



   Machine Pictures



K Span Roof Panel Roll Forming Machine For Coil Width 914mm , 17.7kw Capacity Large Power
