Round Downspout Machine with Hydraulic Cutting / Downspout Roll Forming Machine

Round Downspout Machine with Hydraulic Cutting / Downspout Roll Forming Machine

Round Downspout Machine

Downspout Roll Forming Machine

Place of Origin:

China

Brand Name:

TECHWELL

Certification:

CE

Model Number:

TW-GTM

Contact Us

Request A Quote
Product Details
Cutting Method:
Hydraulic Cutting
Material:
Aluminum / Steel / Copper
Thickness:
0.4-0.8mm
Speed:
30-45ft / Min
Voltage:
380 V, 3 Phase 50Hz
Machine Frame:
A3 Steel, Thickness 18mm
Product Description

Downspout Roll Forming Machine for Making Steel Round Downpipe with Hydraulic Cutting



   A). Main Conponents of Downpipe Former


Decoiler ---------------------------------------------- 1 Unit

Feeding guide -------------------------------------- 1 Unit

main roll forming machine ------------------------ 1 Unit

Hydraulic Cutting device -------------------------- 1 Unit

Hydraulic Station ----------------------------------- 1 Unit

PLC computer control ----------------------------- 1 Unit

Output table ----------------------------------------- 1 Unit

Elbow machine -------------------------------------- 1 Unit



   B). Working Flow of Downpipe Former


Decoiler--> Coil sheet guiding and feeding --> Roll forming machine with safty guard--> Tighten Device -> Cut to length --> Out-put Table --> Curving machine



   C). Main Specification of Downpipe Former



  • Main motor power: 7.5Kw
  • Number of roll stand: About 20 stands
  •  Forming speed: 6-12m/min
  • Voltage: 380 V, 3 Phase 50Hz ( or depend on customer’s requirement )
  • Dimension of machine: About 12000mm*1100mm*1200mm
  • Machine wight: about 12 Ton
  • Material of Axis: High grade 45# steel
  • Diameter of Axis: φ75mm
  • Material of Roller: High grade 45#, polished and coated with 0.05mm Chrome Surface.
  • Materical of Machine Frame: A3 Steel, thickness 18mm
  • Electrical Control: PLC Frequency Control System with touch screen
  • PLC: PANASONIC Brand
  • Encoder: OMRON Brand
  • Transducer: PANASONIC Brand



   D). Applications of Downpipe Former



Rainwater downpipe, Downspout, Rainspout, Water pipe, Drainpipe



   E). Competitive Advantages



1. High Quality

2. Reasonable Price

3. Good Aftersale Service

4. 1 Year Warranty

5. More Than 10 Years Experience

6. Factory Visit



   F). More Machine Pictures



Round Downspout Machine with Hydraulic Cutting / Downspout Roll Forming Machine 0

Round Downspout Machine with Hydraulic Cutting / Downspout Roll Forming Machine 1



   G). FAQ



Q: Do you sell only standard machines?

A: No, most of our machines are built according to customers specifications, using top brand name components.



Q: What size decoiler can you supply us with?

A: From 5-ton decoiler to a 25-ton motorised hydraulic decoiler.



Q: Do you have a warranty on your machines?

A: One year warranty excluding electrical components.



Q: Do you have instruction manuals?

A: We provide you with instruction manuals, electricity layouts, civil requirements, and machine drawings.



Q: Once a machine arrives at our factory what happens then?

A: We will send you a technician or engineer that will commission and install your machine, with training for your staff if required at a separate fee.



Q: What do I need to offload my machine from the container?

A: You are not responsible for the offloading of your machinery, and it is recommended that you use a reputable rigging company.



   H). More Contact Methods & Reference Videos



Item Contact Methods
Contact Person Lemon
E-mail / Skype sales@wxtechwell.com
Tel / Whatsapp +86-15861597732
Reference Videos

https://youtu.be/T7n-n9DOa9w

https://youtu.be/gkBqhWdUwmI
