Active Uncoiling , Hydraulic To Expand 5, 10, 15 Ton Hydraulic Uncoiler / Decoiler With Coil Width 1500mm

China Active Uncoiling , Hydraulic To Expand 5, 10, 15 Ton Hydraulic Uncoiler / Decoiler With Coil Width 1500mm supplier
Active Uncoiling , Hydraulic To Expand 5, 10, 15 Ton Hydraulic Uncoiler / Decoiler With Coil Width 1500mm supplier Active Uncoiling , Hydraulic To Expand 5, 10, 15 Ton Hydraulic Uncoiler / Decoiler With Coil Width 1500mm supplier Active Uncoiling , Hydraulic To Expand 5, 10, 15 Ton Hydraulic Uncoiler / Decoiler With Coil Width 1500mm supplier

Large Image :  Active Uncoiling , Hydraulic To Expand 5, 10, 15 Ton Hydraulic Uncoiler / Decoiler With Coil Width 1500mm

Product Details:

Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-DECOILER

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Contact Now
Detailed Product Description
Decoiler Type: Hydraulic Decoiler / Uncoiler Weight Capacity: 5/7/10/15T
Uncoiling Speed: 0-15m/min Coil Width: Max. 1500mm
Electric Condition: 380V/3Phase/ 50HZ Pressure Of Hydraulic System: 6.3Mpa

Active Uncoiling, Hydraulic To Expand 5, 10, 15 Ton Hydraulic Uncoiler / Decoiler With Coil Width 1500mm



   Introduction of Hydraulic Decoiler / Uncoler





  • Hydraulic uncoiler is the specific machine for uncoil. There are three or four rake fanning strip, connected by dovetail groove, installed on the mandrel.



  • In the end of the the fanning strip installed a radial slide incase it moves to the shaft. But it can open and shrink along the radial direction. The tail of the drum shaft connects to the rotatable cylinder. The cylinder piston rod drives the forward tetragonal shaft move along the shaft by the draw bar in the middle on it. The fanning strip would be lead to open or shrink and add the diameter of the coiling block.



  • This machine can make stretch coil-deliver coil automatically, the speed of which is same with the forming machine. It is a matching machine for colored steel equipment. In order to save human recourse and lower labor cost, it is better to work with colored steel mould machine and stacker, with which it formed a completely porducing line.



  • This machine is compose of feed main machine, hydraulic station, CNC control system.



   Main Specifications of Hydraulic Decoiler





 Decoiler type  Hydraulic decoiler
 Feeding type  Active uncoiling, hydraulic to expand
 Weight capacity  5/7/10/15 Ton
 Coil width  Max. 1500mm
 I.D  508-610mm
 O.D  1300mm
 Material of main shaft 40Cr
Outline dimentision  ablut 3110x1650x1780mm
 Hydraulic motor power  2.5Kw
 Uncoiling speed  0-15m/min
 Capacity of hydraulic station  40L
 Hydraulic system pressure  6.3Mpa
 Coil car stoke  2.5m
 Pressure of hydraulic system  6.3Mpa
 Weight of coil beared by car  10Ton





Active Uncoiling , Hydraulic To Expand 5, 10, 15 Ton Hydraulic Uncoiler / Decoiler With Coil Width 1500mm





   Competitive Advantages



1. Durable and widely used products

2.Simple to operate when assemble

3.Direct manufacturer, provide with high quality and best price.

4.Provide sample in free.

5.Products and design solution supplied fast and freely

6.Best design oriented for your special requirements





   More Machine Pictures





Active Uncoiling , Hydraulic To Expand 5, 10, 15 Ton Hydraulic Uncoiler / Decoiler With Coil Width 1500mm





   Pictures of Loading the Container



Active Uncoiling , Hydraulic To Expand 5, 10, 15 Ton Hydraulic Uncoiler / Decoiler With Coil Width 1500mm
