Place of Origin:
China
Brand Name:
TECHWELL
Certification:
CE, ISO
Model Number:
C80-300
Contact Us
GI. Carbon Steel C Section Roll Forming Machine With 1.5 Inch Chain of Transmission
Main Specifications of C Purlin Roll Former
| Material | GI, Carbon steel |
| Material thickness | 1.5-3.0mm |
| Weight of machine | about 10 Ton |
| Decoiler | Manual or hydraulic decoiler ( customer can choose ) |
| Weight capacity of decoiler | 3 Ton |
| Forming station | 14 |
| Principle axis | 75mm diameter |
| Forming speed | 0-15m/min |
| Drive type | chain transmission |
| Roller material | GCr15 steel, quenched and heated process |
| Main power | 15 KW |
| Hydraulic power | 11 KW |
| Punching | hydraulic punching |
| Electrical Control | PLC Frequency Control System with touch screen |
| PLC | PANASONIC Brand |
| Encoder | OMRON Brand |
| Transducer | PANASONIC Brand |
Main Components
Reference Profile Drawing
Working Flow Process
Decoiler --- Fedding & Leveling --- Roll Forming --- Punching --- Cut-to-length --- Run out table
Applications
C purlin, c shaped purlin, c channel, lip channel, c section, c profile, c shape, steel c purlin, c purlin steel structure
Competitive Advantaegs
Machine Pictures
