Manual / Hydraulic Double Head Decoiling Machine With 0-15m / Min Uncoiling Speed

China Manual / Hydraulic Double Head Decoiling Machine With 0-15m / Min Uncoiling Speed supplier

Large Image :  Manual / Hydraulic Double Head Decoiling Machine With 0-15m / Min Uncoiling Speed

Product Details:

Place of Origin: China
Brand Name: TECHWELL
Certification: CE, ISO
Model Number: TW-DECOILER

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 Sets
Detailed Product Description
Decoiler Type: Double Head Decoiler Machine Uncoiling Speed: 0-12m/min
Coil Expansion: Manual Expansion Or Hydraulic Expanding, Tension Weight Capacity Of Decoiler: 3Ton / 5Ton
Coil I.D: 480-530mm Coil O.D: Max. 1500mm

Manual / Hydraulic Double Head Decoiling Machine With 0-15m/Min Uncoiling Speed





   Description of Uncoiling Machine



This machine is made up of support shelf, principal axis box and material shelf. The principal axis is a whole body

and has a long axis to support material shelf. Its small volume, loading convenient and has good flexibility.



1. save the material changing time ,improve production efficiency.

2. suitable for fast punching speed like stator rotor,and CE sheet ect

3. be able to work with straightener.

4. install the motor and the electric control to change into motive stand.

5. install the left and right shifter is available if material is too narrow .





   Main Technical Parameters



  1. Decoiler type: Manual rotary decoiler machine
  2. Weight capacity of decoiler: 3Ton / 5Ton
  3. Double heads, turn 180 degree
  4. Coil I.D: 480-520mm
  5. Coil O.D: Max. 1500mm
  6. Width of strip: 120-350mm (Depend on customer's requirement)
  7. Expansion Type: Manual expansion or Hydraulic expanding, tension
  8. Uncoiling speed: 0-15m/min
  9. Material of main shaft: 40Cr



   Competitive Advantages



High Quality

Reasonable Price

Good after Service

1 Year Warranty

More Than 10 Years Experience

Simple to operate when assemble

Easy to handle the products

Direct manufacturer, provide with high quality and best price.





   More Machine Pictures



Manual / Hydraulic Double Head Decoiling Machine With 0-15m / Min Uncoiling Speed





   Workshop Machine Pictures



Manual / Hydraulic Double Head Decoiling Machine With 0-15m / Min Uncoiling Speed
