0 - 15m/min Forming Speed , 0.4 - 0.8mm Rainwater Seamless Gutter Machine With Hydraulic Decoiler

China 0 - 15m/min Forming Speed , 0.4 - 0.8mm Rainwater Seamless Gutter Machine With Hydraulic Decoiler supplier
0 - 15m/min Forming Speed , 0.4 - 0.8mm Rainwater Seamless Gutter Machine With Hydraulic Decoiler supplier 0 - 15m/min Forming Speed , 0.4 - 0.8mm Rainwater Seamless Gutter Machine With Hydraulic Decoiler supplier 0 - 15m/min Forming Speed , 0.4 - 0.8mm Rainwater Seamless Gutter Machine With Hydraulic Decoiler supplier 0 - 15m/min Forming Speed , 0.4 - 0.8mm Rainwater Seamless Gutter Machine With Hydraulic Decoiler supplier

Large Image :  0 - 15m/min Forming Speed , 0.4 - 0.8mm Rainwater Seamless Gutter Machine With Hydraulic Decoiler

Product Details:

Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-GM5

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 60-70 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Contact Now
Detailed Product Description
Material Thickness: 0.4-0.8mm Decoiler: Manual Or Hydraulic Decoiler
Weight Capacity Of Decoiler: 3T Forming Station: 16
Working Speed: 0-15m/min Main Motor Power: 3Kw




0 - 15m/min Forming Speed, 0.4 - 0.8mm Rainwater Gutter Machine With Hydraulic Decoiler











  Main Specifications of Gutter Machine







  • Material thickness: 0.4-0.8mm
  • Decoiler: Manaul or hydraulic decoiler
  • Weight capacity of decoiler: 3 Ton
  • Forming Station: 16
  • Main motor power: 3KW
  • Hydraulic power: 7.5KW
  • Forming Speed: 0-15m/min
  • PLC: Panasonic Brand
  • Cutting blade material: Cr12
  • Cutting: Hydraulic cutting
  • Drive: Chain transmission
  • Electrical Control: PLC Frequency Control System with touch screen
  • PLC: PANASONIC Brand
  • Encoder: OMRON Brand
  • Transducer: PANASONIC Brand








  Main Components







  • Decoiler ---------------------------------------------- --- 1 Unit
  • Feeding guide ------------------------------------------ 1 Unit
  • main roll forming machine ---------------------------- 1 Unit
  • Hydraulic cutting device ------------------------------- 1 Unit
  • Hydraulic Station ---------------------------------------- 1 Unit
  • PLC computer control -------------------------------- 1 Unit
  • Output table -------------------------------------------- 1 Unit









  Working Flow






Decoiler--> Coil sheet guiding and feeding --> Roll forming machine --> Cut to length --> Out-put Table







  Gutter Profile Drawing







0 - 15m/min Forming Speed , 0.4 - 0.8mm Rainwater Seamless Gutter Machine With Hydraulic Decoiler



0 - 15m/min Forming Speed , 0.4 - 0.8mm Rainwater Seamless Gutter Machine With Hydraulic Decoiler











  Applications





Rainwater gutter, k gutter, half round gutter, box gutter ,seamless gutter





0 - 15m/min Forming Speed , 0.4 - 0.8mm Rainwater Seamless Gutter Machine With Hydraulic Decoiler

0 - 15m/min Forming Speed , 0.4 - 0.8mm Rainwater Seamless Gutter Machine With Hydraulic Decoiler









  Our Advantage





  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience









  Gutter Machine Pictures









0 - 15m/min Forming Speed , 0.4 - 0.8mm Rainwater Seamless Gutter Machine With Hydraulic Decoiler

0 - 15m/min Forming Speed , 0.4 - 0.8mm Rainwater Seamless Gutter Machine With Hydraulic Decoiler







   Introduction of Our Company





0 - 15m/min Forming Speed , 0.4 - 0.8mm Rainwater Seamless Gutter Machine With Hydraulic Decoiler









  Certificate









0 - 15m/min Forming Speed , 0.4 - 0.8mm Rainwater Seamless Gutter Machine With Hydraulic Decoiler
