80mm, 100mm Or 120mm Custom Round Downspout Roll Forming Machine for Rainwater Downpipe

80mm, 100mm Or 120mm Custom Round Downspout Roll Forming Machine for Rainwater Downpipe

Down Pipe Roll Forming Machine

Downspout Roll Forming Machine

Place of Origin:

China

Brand Name:

TECHWELL

Certification:

CE

Model Number:

TW-DP100

Contact Us

Request A Quote
Product Details
Working Speed:
0-15m/min (excluding Cutting Time)
Roller Material:
45# High Grade Steel, And Roller Surface With Hard Chrome ≥ 0.05mm
Forming Material:
PPGI, Aluminum
Forming Motor Power:
7.5KW
Product Description

80m, 100mm Or 120mm Custom  Round Downspout Roll Forming Machine for Rainwater Downpipe



   Description



Our downspout roll forming machine mainly consists of uncoiler, roll forming system, cutting equipment, protective guard, hydraulic system, control system and out-put table. It can make curve for down pipe to meet the requirement of practical engineering projects.





  Main Specifications



  • Main motor power: 7.5Kw
  • Number of forming station: About 20
  • Forming speed of round downspout roll forming machine: 6-12m/min
  • Voltage: 380 V, 3 Phase 50Hz ( or depend on customer’s requirement )
  • Dimension of machine: About 12000mm*1100mm*1200mm
  • Machine wight: about 12 Ton
  • Material of Axis: High grade 45# steel
  • Diameter of Axis: φ75mm
  • Material of Roller: High grade 45#, polished and coated with 0.05mm Chrome Surface.
  • Materical of Machine Frame: A3 Steel, thickness 18mm
  • Electrical Control: PLC Frequency Control System with touch screen
  • PLC: PANASONIC Brand
  • Encoder: OMRON Brand
  • Transducer: PANASONIC Brand



  Reference Rainspout Drawing



80mm, 100mm Or 120mm Custom Round Downspout Roll Forming Machine for Rainwater Downpipe 0

80mm, 100mm Or 120mm Custom Round Downspout Roll Forming Machine for Rainwater Downpipe 1





80mm, 100mm Or 120mm Custom Round Downspout Roll Forming Machine for Rainwater Downpipe 2







   Main Components



Manual Decoiler 1 Unit
Pinch Feeding 1 Unit
Main Roll Forming 1 Unit
Hydraulic Cutting (machine stop to cut) 1 Unit
Hydraulic Station 1 Unit
Electrical Control Board 1 Unit
Run out Support Table 1 Unit
Elbow Machine 1 Unit





  Working Flow


Decoiler--> Coil sheet guiding and feeding --> Roll forming machine with safty guard--> Tighten Device -> Cut to



length --> Out-put Table --> Curving machine







  Applications





Rainwater downpipe, downspout, rainspout, water pipe, drainpipe
