Steel Structure C Shaped Purlin Roll Forming Machine for Making C Purlin Profile by Chain Drive

China Steel Structure C Shaped Purlin Roll Forming Machine for Making C Purlin Profile by Chain Drive supplier
Steel Structure C Shaped Purlin Roll Forming Machine for Making C Purlin Profile by Chain Drive supplier Steel Structure C Shaped Purlin Roll Forming Machine for Making C Purlin Profile by Chain Drive supplier Steel Structure C Shaped Purlin Roll Forming Machine for Making C Purlin Profile by Chain Drive supplier Steel Structure C Shaped Purlin Roll Forming Machine for Making C Purlin Profile by Chain Drive supplier

Large Image :  Steel Structure C Shaped Purlin Roll Forming Machine for Making C Purlin Profile by Chain Drive

Product Details:

Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-C300

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Contact Us
Packaging Details: Standard Packing
Delivery Time: 55-65 Working Days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 Sets
Contact Now
Detailed Product Description
Material Thickness: 1.5- 3.0mm Hydraulic Power: 11KW
Drive Type: 1.5' Chain Transmission Forming Speed: 0-15m/ Min
Forming Station: 14 Steps (Depend On Profile) Material: Q235, Carbon Steel, Galvanized Coil

Steel Structure C Shaped Purlin Roll Forming Machine for Making C Purlin Profile by Chain Drive

   A). Main Components


1.Decoiler 1 Unit
2.Feeding & Leveling 1 Unit
3.Main roll forming machine  1 Unit
4.Hydraulic cutting device  1 Unit
5.Hydraulic Station 1 Unit
6.PLC computer control 1 Unit
7.Output table  1 Unit



   B). Work Flowing
Decoiler --- Feeding & Leveling --- Roll Forming ---  Cut-to-length --- Run out table

   C). Main Specifications


1.MaterialGI, Carbon steel
2.Material thickness1.5-3.0mm
3.Machine diameterabout 11500x1500x1300mm ( LXWXH )
4.Weight of machineabout 10 Ton
5.DecoilerManual or hydraulic decoiler ( customer can choose )
6.Weight capacity of decoiler5 Ton
7.Forming station14
8.Principle axis75mm diameter
9.Forming speed0-15m/min
10.Drive type1.5' chain transmission
11Roller materialGCr15 steel, quenched and heated process
12.Main power15KW
13.Hydraulic power11KW
14.TransducerPANASONIC Brand
15Electrical ControlPLC Frequency Control System with touch screen
16.PLCPANASONIC Brand
17.EncoderOMRON Brand



   D). Applications

C purlin, C shaped purlin, C channel, Lip channel, C section, C profile, C shape, Steel c purlin, C purlin steel structure

   E). Competitive Advantages

1. High Quality
2. Reasonable Price
3. Good after Service
4. One Year Warranty
5. More Than 10 Years Experience
6. Free Machiner Design

   F). More Machine Pictures
Steel Structure C Shaped Purlin Roll Forming Machine for Making C Purlin Profile by Chain Drive
Steel Structure C Shaped Purlin Roll Forming Machine for Making C Purlin Profile by Chain Drive

   G). Customer Visiting

Steel Structure C Shaped Purlin Roll Forming Machine for Making C Purlin Profile by Chain Drive

   H). Machine To Container

Steel Structure C Shaped Purlin Roll Forming Machine for Making C Purlin Profile by Chain Drive

   I). FAQ

Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available.

Q: Do you have a warranty on your machines?
A: One year warranty excluding electrical components.

Q: Once we've bought a machine from you, are you able to supply us with material?
A: We can assist you in finding the appropriate materials to suit your machine.

Q: Do you sell only standard machines?
A: No, most of our machines are built according to customers specifications, using top brand name components.

Q: What size decoiler can you supply us with?
A: From 5-ton decoiler to a 25-ton motorised hydraulic decoiler.

Q: Do you have instruction manuals?
A: We provide you with instruction manuals, electricity layouts, civil requirements, and machine drawings.

Q: Once a machine arrives at our factory what happens then?
A: We will send you a technician or engineer that will commission and install your machine, with training for your staff if required at a separate fee.
