W Beam Two Wave Guardrail Roll Forming Machine

W Beam Two Wave Guardrail Roll Forming Machine
W Beam Two Wave Guardrail Roll Forming Machine

Large Image :  W Beam Two Wave Guardrail Roll Forming Machine

Product Details:
Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-W312
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Detailed Product Description
Material Thickness: 2-4mm Forming Station: About 15 Stations
Axis Diameter: ¢100mm Working Speed: 10-12m/min
Main Power: 30KW Voltage: 380V, 3 Phase 50Hz
High Light:

2 wave Guardrail Roll Forming Machine

,

W Beam Guardrail Roll Forming Machine

,

2 wave highway guardrail machine

Highway Guardrail Roll Forming Machine Crash Barrier W Beam Two Wave Rail Section Making Machine



What is the most impoerant for Highway Guard Rail Roll Forming Machine/express way making machine/guardrail bending machine. It is punching system. When Highway Guard Rail Roll Forming Machine/express way making machine/guardrail bending machine installation, the punching holes are important. So when you order Highway Guard Rail Roll Forming Machine/express way making machine/guardrail bending machine, you must buy strong Highway Guard Rail Roll Forming Machine/express way making machine/guardrail bending machine and punching system.



This 3 wave guardrail roll forming machine mainly consists of decoiler, guide device, levelling system, hydraulic station, punching, roll forming system, cutting system and runout table.

Thi

  • Material Thickness: 2-4mm
  • Forming Station: 15 excluding the feeding rollers and leveling rollers
  • 7 Rollers leveling
  • Principal Axis Diameter: ¢100mm
  • Working Speed: 10-12m/min
  • Main Power: 30KW
  • Leveling Power: 2.2KW
  • Hydraulic Power: 15KW
  • Dimension of Machine: 11500MM X 2000 MMX1600MM ( LXWXH )
  • Gross Weight of Machine: about 18 Ton
  • Voltage: 380V, 3 Phase 50Hz




    Main Components



  • Hydraulic Decoiler ------------------------------------------ 1 Unit
  • Leveling and Feeding Guide ------------------------------1 Unit
  • Punching Device ------------------------------------------- 1 Unit
  • Roll Forming Machine -------------------------------------- 1 Unit
  • Hydraulic Cutting ------------------------------------------ 1 Unit
  • Hydraulic Station ------------------------------------------ 1 Unit
  • PLC Contol System ---------------------------------------- 1 Unit
  • Runout Table ---------------------------------------------- 1 Unit
  • Spare Coupling -------------------------------------------- 1 Unit





W Beam Two Wave Guardrail Roll Forming Machine 0





   Reference Drawing



W Beam Two Wave Guardrail Roll Forming Machine 1





   Our Advantage





  • High Quality
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience

  Machine Picture



W Beam Two Wave Guardrail Roll Forming Machine 2









  Factory Pictures



W Beam Two Wave Guardrail Roll Forming Machine 3

W Beam Two Wave Guardrail Roll Forming Machine 4



  Certificate



W Beam Two Wave Guardrail Roll Forming Machine 5
