Steel C Channel / C Profile / Lip Channel Roll Forming Machine TW-C300

Steel C Channel / C Profile / Lip Channel Roll Forming Machine TW-C300
Steel C Channel / C Profile / Lip Channel Roll Forming Machine TW-C300 Steel C Channel / C Profile / Lip Channel Roll Forming Machine TW-C300 Steel C Channel / C Profile / Lip Channel Roll Forming Machine TW-C300 Steel C Channel / C Profile / Lip Channel Roll Forming Machine TW-C300

Large Image :  Steel C Channel / C Profile / Lip Channel Roll Forming Machine TW-C300

Product Details:
Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-C300
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Detailed Product Description
Raw Material: Galvanized Steel Sheet Roller Material: GCr15 Steel, Quenched And Heated Process
Forming Stations: 18 Stations PLC Control System: PANASONIC
Main Power: 11KW Hydraulic Power: 7.5KW
High Light:

CZ Purlin Roll Forming Machine

,

C Purlin Roll Forming Machine

Steel C Channel / C Profile / Lip Channel Roll Forming Machine With 1.5-3.0mm Thickness TW-C300






   Main Specifications of Lip Channel Roll Forming Machine





NO Item Parameter Remark
1 Suitable Type Galvanized Coil
Width Depend on profile
Thickness 1.5-3.0mm
Yield Strength Max. 350Mpa
2 Forming Station about 18 Stations Depend on final design
3 Forming Speed about 0-15m/min excluding punching, cutting time
4 Shaft Diameter 80mm
5 Roller Material GCr15 Steel With Hard Chrome
6 Drive Type Gear Box Drive
7 Punching Model Hydraullic Post Punching
8 Punching Groups Depend on hole patterns
9 Cutting Model Hydraulic Cutting
10 Power Source Type 380V/3PH/50HZ Or Customized
Main Power 11 KW
Hydraulic power 7.5KW
11 PLC Control System PANASONIC Operation; Screen + Button





   Main Components





  • Decoiler ----------------------------------------------------------------------- 1 Unit
  • Feeding & Leveling --------------------------------------------------------- 1 Unit
  • Main roll forming machine ------------------------------------------------- 1 Unit
  • Hydraulic punching device ------------------------------------------------ 1 Unit
  • Hydraulic cutting device --------------------------------------------------- 1 Unit
  • Hydraulic Station ------------------------------------------------------------ 1 Unit
  • PLC computer control ----------------------------------------------------- 1 Unit
  • Output table ------------------------------------------------------------------ 1 Unit





   Application





C purlin, c shaped purlin, c channel, lip channel, c section, c profile, c shape, steel c purlin, c purlin steel structure



Steel C Channel / C Profile / Lip Channel Roll Forming Machine TW-C300 0





   Reference Profile Drawing





Steel C Channel / C Profile / Lip Channel Roll Forming Machine TW-C300 1





   Our Advantage







High Quality

Reasonable Price

Good after Service

1 Year Warranty

More Than 10 Years Experience

Simple to operate when assemble

Easy to handle the products

Direct manufacturer, provide with high quality and best price







   Workshop Machine Pictures



Steel C Channel / C Profile / Lip Channel Roll Forming Machine TW-C300 2
