1.5 - 3.0mm Thickness Top Hat Purlin Roll Forming Machine With Hydraulic Cutting, TW-HCM100







  Main Specifications of Top Hat Purlin Roll Forming Machine





  • Material: GI, Carbon steel
  • Material thickness: 1.5-3.0mm
  • Main power: 15KW
  • Machine diameter: about 11500x1500x1300mm ( LXWXH )
  • Weight of machine: about 10 Ton
  • Main Technical Specification:
  • Decoiler: Manual or hydraulic decoiler ( customer can choose )
  • Weight capacity of decoiler: 5 Ton
  • Forming station: 18
  • Principle axis: 75mm diameter
  • Forming speed: 0-15m/min
  • Drive type: 1.5' chain transmission
  • Roller material: GCr15 steel, quenched  and heated process
  • Main power: 15KW
  • Hydraulic power: 7.5KW
  • Electrical Control: PLC Frequency Control System with touch screen
  • PLC: PANASONIC Brand
  • Encoder: OMRON Brand
  • Transducer: PANASONIC Brand









  Work Flowing






Decoiler --- Fedding & Leveling --- Punching --- Roll Forming --- Cut-to-length --- Run out table







  Main Component





  • Decoiler ----------------------------------------------- 1 Unit
  • Feeding & Leveling ------------------------------------ 1 Unit
  • Hydraulic punching device ----------------------------- 1 Unit
  • Main roll forming machine ----------------------------- 1 Unit
  • Hydraulic cutting device ------------------------------- 1 Unit
  • Hydraulic Station -------------------------------------- 1 Unit
  • PLC computer control --------------------------------- 1 Unit
  • Output table ------------------------------------------ 1 Unit







  Application





Top Hat Channel, Furring Channel, Hat Channel, Ridge Channel, Top Furring Channel...





  Our Advantage





  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience







  Reference Drawing





1.5 - 3.0mm Thickness Top Hat Purlin Roll Forming Machine With Hydraulic Cutting, TW-HCM100 0











  Factory Pictures









1.5 - 3.0mm Thickness Top Hat Purlin Roll Forming Machine With Hydraulic Cutting, TW-HCM100 1

1.5 - 3.0mm Thickness Top Hat Purlin Roll Forming Machine With Hydraulic Cutting, TW-HCM100 2
