Product Description

L Section, Wall Angle, L Shape, L Profile, Steel Angle Roll Forming Machine TW-L50

Main Specifications of Steel Angle Roll Forming Machine

Material: GI or Carbon steel
Material thickness: 1.0-2.0mm or 2.0-5.0mm ( depend on custome’s requirement )
Main power: 4KW
Forming station: 8-11 stations
Weight of machine: about 4 Ton
Decoiler: manual decoiler
Weight capacity of decoiler: 3 Ton
Drive: Chain transmission
Machine post thickness: S18
Cutting: Hydraulic cutting
Hydraulic power: 3KW
Cutting tolence: +/-2mm
Electrical Control: PLC Frequency Control System with touch screen
PLC: PANASONIC Brand
Encoder: OMRON Brand
Transducer: PANASONIC Brand

Working Flow

Decoiler --- Fedding & Leveling --- Roll Forming --- Cut-to-length --- Run out table

Reference Drawings

L Section, Wall Angle, L Shape, L Profile, Steel Angle Roll Forming Machine TW-L50 0

L Section, Wall Angle, L Shape, L Profile, Steel Angle Roll Forming Machine TW-L50 1

L Section, Wall Angle, L Shape, L Profile, Steel Angle Roll Forming Machine TW-L50 2

Applications

Metal angle, steel angle, angle steel, l section, wall angle, l shape, l profile

Our Advantage

High Quality
Reasonable Price
Good after Service
1 Year Warranty
More Than 10 Years Experience

Machine Pictures
