0.5mm Steel Angle, Angle Steel Roll Forming Machine For L Shape, L Profile TW-L50

0.5mm Steel Angle, Angle Steel Roll Forming Machine For L Shape, L Profile TW-L50
0.5mm Steel Angle, Angle Steel Roll Forming Machine For L Shape, L Profile TW-L50 0.5mm Steel Angle, Angle Steel Roll Forming Machine For L Shape, L Profile TW-L50

Large Image :  0.5mm Steel Angle, Angle Steel Roll Forming Machine For L Shape, L Profile TW-L50

Product Details:
Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-L50
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Detailed Product Description
High Light:

CZ Purlin Roll Forming Machine

,

C Purlin Roll Forming Machine





0.5mm Steel Angle, Angle Steel Roll Forming Machine For L Shape, L Profile TW-L50







  Main Specifications of Steel Angle Roll Forming Machine





  • Material: GI or Carbon steel
  • Material thickness: 1.0-2.0mm or 2.0-5.0mm ( depend on custome’s requirement )
  • Main power: 4KW
  • Forming station: 8-11 stations
  • Weight of machine: about 4 Ton
  • Decoiler: manual decoiler
  • Weight capacity of decoiler: 3 Ton
  • Drive: Chain transmission
  • Machine post thickness: S18
  • Cutting: Hydraulic cutting
  • Hydraulic power: 3KW
  • Cutting tolence: +/-2mm
  • Electrical Control: PLC Frequency Control System with touch screen
  • PLC: PANASONIC Brand
  • Encoder: OMRON Brand
  • Transducer: PANASONIC Brand







  Working Flow




Decoiler --- Fedding & Leveling --- Roll Forming --- Cut-to-length --- Run out table





  Reference Drawings





0.5mm Steel Angle, Angle Steel Roll Forming Machine For L Shape, L Profile TW-L50 0

0.5mm Steel Angle, Angle Steel Roll Forming Machine For L Shape, L Profile TW-L50 1

0.5mm Steel Angle, Angle Steel Roll Forming Machine For L Shape, L Profile TW-L50 2







  Applications





Metal angle, steel angle, angle steel, l section, wall angle, l shape, l profile





  Our Advantage





  • High Quality
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience









  Machine Pictures





0.5mm Steel Angle, Angle Steel Roll Forming Machine For L Shape, L Profile TW-L50 3









  Factory Pictures







0.5mm Steel Angle, Angle Steel Roll Forming Machine For L Shape, L Profile TW-L50 4

0.5mm Steel Angle, Angle Steel Roll Forming Machine For L Shape, L Profile TW-L50 5

0.5mm Steel Angle, Angle Steel Roll Forming Machine For L Shape, L Profile TW-L50 6









0.5mm Steel Angle, Angle Steel Roll Forming Machine For L Shape, L Profile TW-L50 7







  Certificate





0.5mm Steel Angle, Angle Steel Roll Forming Machine For L Shape, L Profile TW-L50 8
