HRC, CRC, GI, 1.5 - 3.0mm Thickness U Profile / Section Roll Forming Machine TW-U100

Name: HRC, CRC, GI, 1.5 - 3.0mm Thickness U Profile / Section Roll Forming Machine TW-U100
Brand: TECHWELL
SKU: TW-U100
Price: 1.00 USD
Availability: InStock
Rating: 4.9 (112 reviews)

Large Image : HRC, CRC, GI, 1.5 - 3.0mm Thickness U Profile / Section Roll Forming Machine TW-U100

Product Details:

Place of Origin:	China
Brand Name:	TECHWELL
Certification:	CE
Model Number:	TW-U100

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Contact Us
Packaging Details:	Standard packing
Delivery Time:	55-65 working days
Payment Terms:	40% T/T in advance, 60% T/T before shipment
Supply Ability:	20 sets

Contact Now

Detailed Product Description

High Light:

Z Purlin Roll Forming Machine

C Purlin Roll Forming Machine

HRC, CRC, GI, 1.5 - 3.0mm Thickness U Profile / Section Roll Forming Machine TW-U100

Main Specifications of U Profile / Section Roll Forming Machine

Material: HRC, CRC, GI
Material thickness: 1.5-3.0mm
Main power: 11KW
Hydraulic power: 5.5KW
Decoiler: Manual or hydraulic decoiler
Weight capacity of decoiler: 5 Ton
Axis diameter: 75mm
Forming Station: 12 stations
Principal axis material: 45# high grade steel, heated and quenched
Roller material: GCr15 steel, quenched and heated process, HRC58-62
Forming speed: 0-20m/min
Drive: Chain transmission
Electrical Control: PLC Frequency Control System with touch screen
PLC: PANASONIC Brand
Encoder: OMRON Brand
Transducer: PANASONIC Brand

Working Flow

Decoiler --- Fedding & Leveling --- Roll Forming --- Cut-to-length --- Run out table

HRC, CRC, GI, 1.5 - 3.0mm Thickness U Profile / Section Roll Forming Machine TW-U100 0

Main Components

Decoiler ---------------------------------------------- 1 Unit
Feeding & Leveling ----------------------------------- 1 Unit
Main roll forming machine ---------------------------- 1 Unit
Hydraulic cutting device ------------------------------ 1 Unit
Hydraulic Station ------------------------------------- 1 Unit
PLC computer control -------------------------------- 1 Unit
Output table ----------------------------------------- 1 Unit

Profile Drawing

HRC, CRC, GI, 1.5 - 3.0mm Thickness U Profile / Section Roll Forming Machine TW-U100 1

Application

u purlin, u shaped purlin, u channel, u section, u profile, u shape, steel u purlin,u purlin steel structure

Our Advantage

High Quality
Reliable
Durable
Reasonable Price
Good after Service
1 Year Warranty
More Than 10 Years Experience

Machine Pictures

HRC, CRC, GI, 1.5 - 3.0mm Thickness U Profile / Section Roll Forming Machine TW-U100 2

HRC, CRC, GI, 1.5 - 3.0mm Thickness U Profile / Section Roll Forming Machine TW-U100 5

Factory Pictures

HRC, CRC, GI, 1.5 - 3.0mm Thickness U Profile / Section Roll Forming Machine TW-U100 6

HRC, CRC, GI, 1.5 - 3.0mm Thickness U Profile / Section Roll Forming Machine TW-U100 7

HRC, CRC, GI, 1.5 - 3.0mm Thickness U Profile / Section Roll Forming Machine TW-U100 8

HRC, CRC, GI, 1.5 - 3.0mm Thickness U Profile / Section Roll Forming Machine TW-U100 9

Certificate

HRC, CRC, GI, 1.5 - 3.0mm Thickness U Profile / Section Roll Forming Machine TW-U100 10
