K-Span Arch Roof Roll Forming Machine For 0.8 - 1.5mm Thickness Large Span Roof Panel

China K-Span Arch Roof Roll Forming Machine For 0.8 - 1.5mm Thickness Large Span Roof Panel supplier
K-Span Arch Roof Roll Forming Machine For 0.8 - 1.5mm Thickness Large Span Roof Panel supplier K-Span Arch Roof Roll Forming Machine For 0.8 - 1.5mm Thickness Large Span Roof Panel supplier K-Span Arch Roof Roll Forming Machine For 0.8 - 1.5mm Thickness Large Span Roof Panel supplier K-Span Arch Roof Roll Forming Machine For 0.8 - 1.5mm Thickness Large Span Roof Panel supplier

Large Image :  K-Span Arch Roof Roll Forming Machine For 0.8 - 1.5mm Thickness Large Span Roof Panel

Product Details:

Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-K610

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Contact Now
Detailed Product Description
Coil Thickness: 0.8-1.5mm Forming Speed: 12-15m/min
Axis Diameter: 85mm Raw Material Width: According Profile
Formign Rollers: GCr15, Quenching Hardness HRC56-62, Chrome Plated Main Motor Power: 15KW

K-Span Arch Roof Roll Forming Machine For 0.8 - 1.5mm Thickness Large Span Roof Panel


  Main Specifications Of K-Span Arch Roof Roll Forming Machine


Coil WidthAccording the profileRolling Speed
Rolling Speed12-15m/min
Rolling Thickness0.8-1.5mm
Control SystemPLC Control
UncoilerManual or Hydraulic Type
Roller StationsAbout 17 Stations (according the final design)
Roller Material45# forge steel, coated with chrome
Shaft Material45# forge steel
Axis Diameter85mm
Cutting TypeHydraulic Cutting
Main Motor Power15 KW
Hydraulic Station Power5.5KW
Hydraulic Pressure12-16Mpa adjustable
Cutting Blade MaterialCr12Mov, quenching58-62
Cutting Tolerance+/-1.5mm
Electrical Source380V, 50HZ, 3Phase
Drive TypeChain Drive



  Working Flow of K-Span Arch Roof Panel

Decoiling—feeding—roll forming—-cut to length—product packing manual—arching—seaming

   Main Components


Decoiler1 Set
TrailerOptional
Engine Power Unit (Generator)Optional
Hydraulic Cut Device With Hydraulic Station1 Set
Main K Span Roll Former1 Set
Control System1 Set
Panel Storage Racks1 Set
Panel Hydraulic Curving Device1 Set
Curved Panel Run Out Table1 Set



  K-Span Profile Drawings



K-Span Arch Roof Roll Forming Machine For 0.8 - 1.5mm Thickness Large Span Roof Panel



  Applications


K Span arched roof, k span roofing, large span roof, no-girder roof panel


   Out-put Table Finished Products

K-Span Arch Roof Roll Forming Machine For 0.8 - 1.5mm Thickness Large Span Roof Panel

  Our Advantages


  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience



  Reference Machine Pictures

 K-Span Arch Roof Roll Forming Machine For 0.8 - 1.5mm Thickness Large Span Roof Panel
