Sandwich Panel Line,
Continuous Sandwich Panel Line
Roof Wall Polyurethane Sandwich Panel Production Line For 30 - 2150mm Roof Wall PU Sandwich Panels
Main Specifications of PU Sandwich Panel Production Line
1. (a) Thickness : roof steel panel 30-150mm and wall steel panel 30-150mm.
(b) PU foam density : 40±5 kg/m³ ( or depend on requrement )
(c) Panel width : 1000mm ( or denpen on customer's requirement )
(d) Thickness of galvanizes color steel coil : 0.4mm~0.75mm
2. The production speed is different according to the panel thickness.
3. Speed of forming machine is 0~12m/min and adjustable. The length and amount of production can be set and count automatically by control panel.
4. Hydraulic material discharge stand can feed steel sheets automatically and keep accuracy during long time operation.
5. Bend saw cutter : Maximum thickness is 200mm. The suction channel is reserved for additional suction system to prevent the dust pollution.
6. The characteristic of this continuous rubber belt sandwich line is ALL parts including forming machine, lamination, conveyor, cutter and auto stacking equipment are synchronized by a central Ratio Setter control system. The user can easily control the speed through the main speed controller (VR).
Summary and Character
Sandwich Panel Profile Drawings For Reference
Referenc Working Flow
Roof Wall PU Sandwich Panel, Insulated Sandwich Panel, Prefabricated House, Prefab House, Mobile House, Cool Room...
Reference PU Sandwich Panel Machine Pictures
