30 - 100mm Rubber Belt PU Sandwich Panel Machine for Polyurethane Sandwich Panels

30 - 100mm Rubber Belt PU Sandwich Panel Machine for Polyurethane Sandwich Panels


   Summary and Character of PU Sandwich Panel Machine

   Main Specifications

1. Uncoiler

1. Motor Power: 3.0KW

2. Hydraulic Power: 2.2Kw

3. Raw Material: color steel sheet, aluminum sheet

4. Inner Diameter of Coil: 500-600mm

5. Outer Diameter of Coil: 1200mm

6. Coil Weight: 10T

7. Sheet Thickness: 0.4-0.8mm

8. Coil Width: 1250mm

2. Coil Car

1. Hydraulic cylinder lift stroke: up panel 0.5m, down panel 0.5m

2. Coil car stroke: 2.5m

3. Pressure of hydraulic system: 6.3Mpa

3. Two Sets of Steel Sheet Transverse Cutting Machines

1. Hydraulic

2. Cut steel sheet according to certain length

3. Two sets of PVC film covering device which applies the PVC film onto the steel sheet

4. Roll Forming Machine

1. Motor power: up panel 4Kw, down panel 7.5Kw

2. Rolling Speed: 0-12m/min

3. Roller Material: 40Cr, surface chrome coated, thickness 0.05mm

4. The way of width adjust: straight track, silk pole, reducer motor adjustable

5. Width adjustable range: 600-1250mm

6. Sheet Thickness: 0.4-0.8mm

5. Pre-heating Room

1. Temperature sensor: hot couple

2. Temperature adjustment: automatic control by temperature control equipment

3. Hot air motor: 18.5KW

4. Heat Type: heated by electricity and air circulate

5. Hot air heater: 200KW

6. Doouble Belt Machine

1. Effective working length: 24m

2. Length & Width of double belt: 1400mm x 267mm

3. Double belt material: Alloy steel

7. Band Saw Cutting Machine

1. Outline dimension of band saw cutting machine: 5500mmx5000mmx 3000mm

2. Run speed of band saw: 1000-1500rpm

3. Rotate diameter of band saw: 550mm

4. Cutting speed of band saw: 50m/min-1000m/min

5. Width of band saw: 30mm

   Sandwich Panel Profile Drawings For Reference

   Applications

Roof Wall PU Sandwich Panel, Insulated Sandwich Panel, Prefabricated House, Prefab House, Mobile House,

Cool Room...

   Our Advantage

• High Quality
• Reliable
• Durable
• Reasonable Price
• Good after Service
• 1 Year Warranty
• More Than 10 Years Experience

   Reference PU Sandwich Panel Machine Pictures
