Rock Wool Insulated Sandwich Panel Machine For Insulated Roof Wall Sandwich Panels

Name: Rock Wool Insulated Sandwich Panel Machine For Insulated Roof Wall Sandwich Panels
Brand: TECHWELL
SKU: TW-RKW1250
Price: 1.00 USD
Availability: InStock
Rating: 4.9 (138 reviews)

Large Image : Rock Wool Insulated Sandwich Panel Machine For Insulated Roof Wall Sandwich Panels

Product Details:

Place of Origin:	China
Brand Name:	TECHWELL
Certification:	CE
Model Number:	TW-RKW1250

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Contact Us
Packaging Details:	Standard packing
Delivery Time:	60-75 working days
Payment Terms:	40% T/T in advance, 60% T/T before shipment
Supply Ability:	20 sets

Contact Now

Detailed Product Description

High Light:

Sandwich Panel Roll Forming Machine

Sandwich Panel Line

Rock Wool Insulated Sandwich Panel Machine For Insulated Roof Wall Sandwich Panels

Technical Specifications

Power Supply: AC380/50-60HZ
Total Power: 32 KW
Production Line Speed: 0-4.05m/min
Equipment overall dimensions: 45000x3000x2800
Product width: 1000mm, 1200mm
Product Thickness: 50-250mm
Annual Output: 600000M2

Rock Wool Insulated Sandwich Panel Machine For Insulated Roof Wall Sandwich Panels 0

Rock Wool Insulated Sandwich Panel Machine For Insulated Roof Wall Sandwich Panels 1

Rock Wool Insulated Sandwich Panel Machine For Insulated Roof Wall Sandwich Panels 2

Rock Wool Insulated Sandwich Panel Machine For Insulated Roof Wall Sandwich Panels 3

Rock Wool Insulated Sandwich Panel Machine For Insulated Roof Wall Sandwich Panels 4

Rock Wool Insulated Sandwich Panel Machine For Insulated Roof Wall Sandwich Panels 6

Rock Wool Insulated Sandwich Panel Machine For Insulated Roof Wall Sandwich Panels 7

Machine Summary

color-steel sandwich plate compound production line can compound the corrugated compound plates for once. The whole set production line is composed of the feed unrolling system, molding system, cutting device, compounding system (rib pressing, glue coating, heating, compounding, flanging, notching, trimming, pneumatic and automatic cutting). The whole process is computer-controlled. It is the necessary equipment for producing the faceplates and wallboards for industrial workshops and warehouse.

Applications

Roof wall sandwich panel, insulated sandwich panel, prefabricated house, prefab house, mobile house, cool room ...

Our Advantage

High Quality
Reliable
Durable
Reasonable Price
Good after Service
1 Year Warranty
More Than 10 Years Experience

Factory Pictures

Rock Wool Insulated Sandwich Panel Machine For Insulated Roof Wall Sandwich Panels 8

Rock Wool Insulated Sandwich Panel Machine For Insulated Roof Wall Sandwich Panels 9

Rock Wool Insulated Sandwich Panel Machine For Insulated Roof Wall Sandwich Panels 10

Rock Wool Insulated Sandwich Panel Machine For Insulated Roof Wall Sandwich Panels 11

Certificate

Rock Wool Insulated Sandwich Panel Machine For Insulated Roof Wall Sandwich Panels 12
