50Hz, 3 Phase Silo Steel Corrugated Sheet Roll Forming Machine With 18 Stations

50Hz, 3 Phase Silo Steel Corrugated Sheet Roll Forming Machine With 18 Stations
50Hz, 3 Phase Silo Steel Corrugated Sheet Roll Forming Machine With 18 Stations 50Hz, 3 Phase Silo Steel Corrugated Sheet Roll Forming Machine With 18 Stations 50Hz, 3 Phase Silo Steel Corrugated Sheet Roll Forming Machine With 18 Stations

Large Image :  50Hz, 3 Phase Silo Steel Corrugated Sheet Roll Forming Machine With 18 Stations

Product Details:
Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-SILO
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 100-120 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Detailed Product Description
Suitable Material: Galvanized Sheet, Aluminum Sheet Material Thickness: 2.0-4.0mm
Max. Feeding Coil Width: 1250mm Forming Station: Approx 18 Stations
Roller Material: GCr15, Quenching HRC 58-62 ° Power Supply: AC440V+/-10%, 50Hz, 3 Phase
High Light:

steel roll forming machine

,

corrugated sheet making machine

50Hz, 3 Phase Silo Steel Corrugated Sheet Roll Forming Machine With 18 Stations



  Main Specifications of Steel Corrugated Sheet Roll Forming Machine



  • Suitable material: Galvanized sheet, Zinc Alumina sheet
  • Material yield strength: 310Mpa
  • Material thickness: 2.5-4.0mm
  • Max. Feeding coil width: 1250mm
  • Machine working speed: 4-8m//min
  • Forming station: approx 18 stations
  • Size of roll shaft:  Ф120mm
  • Roller material: GCr15, quenching HRC 58-62 °
  • Total power: approx 180KW
  • Power supply: AC440V+/-10%, 50Hz, 3 Phase
  • Whole line dimention: about 35M X 4.5M ( L X W )
  • Installation height: 4.5m
  • Total weith of machine: approx 70 tons





   Working Flow


Loading coil car  ->  Un-coiler  ->  guiding device ->  feeder  ->  leveller  ->  shear roll former  ->  hydraulic press  -



>  curving  -> hydraulic cutting  ->  stacker  ->  PLC control





   Reference Drawing



50Hz, 3 Phase Silo Steel Corrugated Sheet Roll Forming Machine With 18 Stations 0

50Hz, 3 Phase Silo Steel Corrugated Sheet Roll Forming Machine With 18 Stations 1

50Hz, 3 Phase Silo Steel Corrugated Sheet Roll Forming Machine With 18 Stations 2





  Application



Steel silo corrugated sheet, steel silo corrugated panel, silo wall sheet, silo corrugated wall sheet, silo wall panel,



silo corrugated wall panel, silo side panel, steel corrugated sheet, steel corrugated wall panel, steel corrugated



panel



50Hz, 3 Phase Silo Steel Corrugated Sheet Roll Forming Machine With 18 Stations 3





  Our Advantage



  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience





  Machine Pictures



50Hz, 3 Phase Silo Steel Corrugated Sheet Roll Forming Machine With 18 Stations 4

50Hz, 3 Phase Silo Steel Corrugated Sheet Roll Forming Machine With 18 Stations 5
