4 - 8m/min Steel Silo Corrugated Wall Panel Roll Forming Machine For Galvanized Sheet






  Main Specifications of Corrugated Wall Panel Roll Forming Machine





  • Suitable material: Galvanized sheet, Zinc Alumina sheet
  • Material yield strength: 310Mpa
  • Material thickness: 2.5-4.0mm
  • Max. Feeding coil width: 1250mm
  • Machine working speed: 4-8m//min
  • Forming station: approx 18 stations
  • Size of roll shaft:  Ф120mm
  • Roller material: GCr15, quenching HRC 58-62 °
  • Total power: approx 180KW
  • Power supply: AC440V+/-10%, 50Hz, 3 Phase
  • Whole line dimention: about 35M X 4.5M ( L X W )
  • Installation height: 4.5m
  • Total weith of machine: approx 70 tons







  Working Flow




Loading coil car  ->  Un-coiler  ->  guiding device ->  feeder  ->  leveller  ->  shear roll former  ->  hydraulic press  ->  curving  -> hydraulic cutting  ->  stacker  ->  PLC control









  Reference Drawing







4 - 8m/min Steel Silo Corrugated Wall Panel Roll Forming Machine For Galvanized Sheet 0

4 - 8m/min Steel Silo Corrugated Wall Panel Roll Forming Machine For Galvanized Sheet 1

4 - 8m/min Steel Silo Corrugated Wall Panel Roll Forming Machine For Galvanized Sheet 2

4 - 8m/min Steel Silo Corrugated Wall Panel Roll Forming Machine For Galvanized Sheet 3









  Application





Steel silo corrugated sheet, steel silo corrugated panel, silo wall sheet, silo corrugated wall sheet, silo wall panel, silo corrugated wall panel, silo side panel, steel corrugated sheet, steel corrugated wall panel, steel corrugated panel





4 - 8m/min Steel Silo Corrugated Wall Panel Roll Forming Machine For Galvanized Sheet 4

4 - 8m/min Steel Silo Corrugated Wall Panel Roll Forming Machine For Galvanized Sheet 5







  Our Advantage



  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience





  Machine Pictures







4 - 8m/min Steel Silo Corrugated Wall Panel Roll Forming Machine For Galvanized Sheet 6

4 - 8m/min Steel Silo Corrugated Wall Panel Roll Forming Machine For Galvanized Sheet 7

4 - 8m/min Steel Silo Corrugated Wall Panel Roll Forming Machine For Galvanized Sheet 8









  Factory Pictures







4 - 8m/min Steel Silo Corrugated Wall Panel Roll Forming Machine For Galvanized Sheet 9

4 - 8m/min Steel Silo Corrugated Wall Panel Roll Forming Machine For Galvanized Sheet 10

4 - 8m/min Steel Silo Corrugated Wall Panel Roll Forming Machine For Galvanized Sheet 11









4 - 8m/min Steel Silo Corrugated Wall Panel Roll Forming Machine For Galvanized Sheet 12







  Certificate





4 - 8m/min Steel Silo Corrugated Wall Panel Roll Forming Machine For Galvanized Sheet 13
