7 Rollers Leveling Expressway Guardrail Roll Forming Machine For Crash Barrier TW-W312

Name: 7 Rollers Leveling Expressway Guardrail Roll Forming Machine For Crash Barrier TW-W312
Brand: TECHWELL
SKU: TW-W312
Price: 1.00 USD
Availability: InStock
Rating: 5 (154 reviews)

Large Image : 7 Rollers Leveling Expressway Guardrail Roll Forming Machine For Crash Barrier TW-W312

Product Details:

Place of Origin:	China
Brand Name:	TECHWELL
Certification:	CE
Model Number:	TW-W312

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Contact Us
Packaging Details:	Standard packing
Delivery Time:	55-65 working days
Payment Terms:	40% T/T in advance, 60% T/T before shipment
Supply Ability:	20 sets

Contact Now

Detailed Product Description

High Light:

Highway Guardrail Forming Machine

C Channel Roll Forming Machine

7 Rollers Leveling Expressway Guardrail Roll Forming Machine For Crash Barrier TW-W312

Summary of Express Guardrail Roll Forming Machine

This expressway guardrail roll forming machine mainly consists of decoiler, guide device, levelling system, hydraulic station, punching, roll forming system, cutting system and runout table.

Thi

Material Thickness: 2-4mm
Forming Station: 15 excluding the feeding rollers and leveling rollers
7 Rollers leveling
Principal Axis Diameter: ￠100mm
Working Speed: 10-12m/min
Main Power: 30KW
Leveling Power: 2.2KW
Hydraulic Power: 15KW
Dimension of Machine: 11500MM X 2000 MMX1600MM ( LXWXH )
Gross Weight of Machine: about 18 Ton
Voltage: 380V, 3 Phase 50Hz

Main Component

Hydraulic Decoiler ------------------------------------------ 1 Unit
Leveling and Feeding Guide -------------------------------- 1 Unit
Punching Device ------------------------------------------- 1 Unit
Roll Forming Machine -------------------------------------- 1 Unit
Hydraulic Cutting ------------------------------------------ 1 Unit
Hydraulic Station ------------------------------------------ 1 Unit
PLC Contol System ---------------------------------------- 1 Unit
Runout Table ---------------------------------------------- 1 Unit
Spare Coupling -------------------------------------------- 1 Unit

7 Rollers Leveling Expressway Guardrail Roll Forming Machine For Crash Barrier TW-W312 0

Reference Drawing

7 Rollers Leveling Expressway Guardrail Roll Forming Machine For Crash Barrier TW-W312 1

7 Rollers Leveling Expressway Guardrail Roll Forming Machine For Crash Barrier TW-W312 2

7 Rollers Leveling Expressway Guardrail Roll Forming Machine For Crash Barrier TW-W312 3

Our Advantage

High Quality
Reasonable Price
Good after Service
1 Year Warranty
More Than 10 Years Experience

Machine Picture

7 Rollers Leveling Expressway Guardrail Roll Forming Machine For Crash Barrier TW-W312 4

7 Rollers Leveling Expressway Guardrail Roll Forming Machine For Crash Barrier TW-W312 5

Factory Pictures

7 Rollers Leveling Expressway Guardrail Roll Forming Machine For Crash Barrier TW-W312 6

7 Rollers Leveling Expressway Guardrail Roll Forming Machine For Crash Barrier TW-W312 7

7 Rollers Leveling Expressway Guardrail Roll Forming Machine For Crash Barrier TW-W312 8

7 Rollers Leveling Expressway Guardrail Roll Forming Machine For Crash Barrier TW-W312 9

Certificate

7 Rollers Leveling Expressway Guardrail Roll Forming Machine For Crash Barrier TW-W312 10
