Detailed Product Description
Material: Q235 Cold Rolled Strip Or Hot-dip Galvanizing Stee Strip Main Motor Power: 18.5Kw
Forming Speed: 0-10m/min Quality Of Stands: About 16 Stations
Controling System: PLC Total Weight: About 13Ton
High Light:

cable tray forming machine

,

cable tray manufacturing machine

Cable Tray Forming Machine With 18 Groups Forming Roller Stand , Roll Forming Equipment



   Main Specification of Cable Tray Roll Forming Machine



  • Suitable Material: Q235 cold rolled strip or Hot-dip Galvanizing stee strip
  • Material Width: 400mm (As per profile)
  • Material Thickness: 1.5-2.5mm
  • Decoiler: Manual or Auto decoiler (Depend on customer's requirement)
  • Coil I.D: 508-610mm
  • Forming Speed: 0-10m/min
  • Forming Stations: About 16 steps
  • Roller Material: GCr15 steel, quench HRC58-62, Chrome plated
  • Shaft Material: 45# steel
  • Drive Type: Chain drive or gearbox (Depend on customer's requirement)
  • Total Power: About 32Kw
  • Cutting: Hydraulic cutting, Cr12Mov, quench HRC58-62
  • Cutting Length Tolerance: +/-1mm
  • PLC: Panasonic Brand
  • Encoder: Omron







   Cable Tray Profile Drawing



Cable Tray Forming Machine With 18 Groups Forming Roller Stand , Roll Forming Equipment 0





Cable Tray Forming Machine With 18 Groups Forming Roller Stand , Roll Forming Equipment 1







   Working Flow



Auoto Decoiler – Tranporting & 9 Rollers Leveling – Servo Feeding -- 100 Ton Punching machine --



Oriented – Transportation – 8 Holes Punching -- Main Forming -- Cutting -- Run out table



Cable Tray Forming Machine With 18 Groups Forming Roller Stand , Roll Forming Equipment 2



   Main Components





Decoiler / Uncoiler 1 Unit
Leveling Device 1 Unit
Servo Feeding 1 Unit
Hydraulic Punching 1 Unit
Main Roll Forming Machine 1 Unit
Hydraulic Cutting 1 Unit
Hydraulic Station 1 Unit
PLC Control Box 1 Unit
Output Tables 2 Units



   Application



Cable tray, cable ladder, cable profile, tray profile
