Interchangeable C Channel Roll Forming Machine for Making 3 kinds of C Purlin Profile

Interchangeable C Channel Roll Forming Machine for Making 3 kinds of C Purlin Profile

Z Purlin Roll Forming Machine

CZ Purlin Roll Forming Machine

Place of Origin:

China

Brand Name:

TECHWELL

Certification:

CE

Model Number:

TW-C100

Contact Us

Request A Quote
Product Details
Material Thickness:
1.5- 3.0mm
Main Power:
7.5KW
Cutting Blade:
Cr12Mov
Forming Speed:
0-15m/ Min
Forming Station:
14 Steps (Depend On Profile)
Material:
Q235, Carbon Steel, Galvanized Coil
Product Description

Interchangeable C Purlin Roll Forming Machine for Making 3 kinds of C Purlin Profile

   A). Main Components


1.Decoiler 1 Unit
2.Feeding & Leveling 1 Unit
3.Main roll forming machine  1 Unit
4.Hydraulic cutting device  1 Unit
5.Hydraulic Station 1 Unit
6.PLC computer control 1 Unit
7.Output table  1 Unit



   B). Work Flowing

Decoiler --- Feeding & Leveling --- Roll Forming --- Cut-to-length --- Run out table

   C). Main Specifications


1.MaterialGI, Carbon steel
2.Material thickness1.5-3.0mm
3.Machine diameterabout 11500x1500x1300mm ( LXWXH )
4.Weight of machineabout 10 Ton
5.DecoilerManual or hydraulic decoiler ( customer can choose )
6.Weight capacity of decoiler5 Ton
7.Forming station14
8.Principle axis75mm diameter
9.Forming speed0-15m/min
10.Drive type1.5' chain transmission
11Roller materialGCr15 steel, quenched and heated process
12.Main power15KW
13.Hydraulic power11KW
14.TransducerPANASONIC Brand
15Electrical ControlPLC Frequency Control System with touch screen
16.PLCPANASONIC Brand
17.EncoderOMRON Brand



   D). Applications

C purlin, C shaped purlin, C channel, Lip channel, C section, C profile, C shape, Steel c purlin, C purlin

steel structure

   E). Competitive Advantages

1. High Quality
2. Reasonable Price
3. Good after Service
4. One Year Warranty
5. More Than 10 Years Experience
6. Free Machiner Design

   F). More Machine Pictures
Interchangeable C Channel Roll Forming Machine for Making 3 kinds of C Purlin Profile 0
Interchangeable C Channel Roll Forming Machine for Making 3 kinds of C Purlin Profile 1
   G). Nearest Customer Visiting

Interchangeable C Channel Roll Forming Machine for Making 3 kinds of C Purlin Profile 2

   H). Machine To Container
Interchangeable C Channel Roll Forming Machine for Making 3 kinds of C Purlin Profile 3

   I). FAQ

Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available.

Q: Once we've bought a machine from you, are you able to supply us with material?
A: We can assist you in finding the appropriate materials to suit your machine.

Q: Do you sell only standard machines?
A: No, most of our machines are built according to customers specifications, using top brand name components.

Q: What size decoiler can you supply us with?
A: From 5-ton decoiler to a 25-ton motorised hydraulic decoiler.

Q: Do you have a warranty on your machines?
A: One year warranty excluding electrical components.

Q: Do you have instruction manuals?
A: We provide you with instruction manuals, electricity layouts, civil requirements, and machine drawings.

Q: Once a machine arrives at our factory what happens then?
A: We will send you a technician or engineer that will commission and install your machine, with training for your staff if required at a separate fee.

   J). More Contact Methods & Reference Videos


ItemContact Methods
Contact PersonLemon
E-mail / Skypesales@wxtechwell.com
Tel / Whatsapp+86-15861597732
Reference Videos

https://youtu.be/K4RN47lJIaQ
https://youtu.be/4pFKlzv_vVU
https://youtu.be/GpPuu0AO_dQ
