High Precision Hydraulic Automatic Cut To Length Machine / Sheet Metal Slitter Cutting Machine With Auto Stacker System

High Precision Hydraulic Automatic Cut To Length Machine / Sheet Metal Slitter Cutting Machine With Auto Stacker System

   Description of Cut To Length Line

• Cutting line for cutting flat rectangular blanks from main coils.
• The lines can be supplied with start-stop shears, flying shears, rotating shears or continuous direct feed. Air cushion, bomb-door type, electromagnetic or vacuum stackers. High-precision levellers of four, five and six heights, computer controlled. Edge trimming may be incorporated..
• Totally computer-controlled with diagnosis, automatic coil feed and quality control.
• For carbon steel, exposed and non exposed material, stainless steel, pre-painted steel, aluminum and other metals.

   Main Technical Data

• Thickness of coil: 0.3-3.0mm
• Width of coil: 1800mm
• Loading capacity of uncoiler: 20T;
• Coil I.D: ф508mm—ф610mm;
• Coil O.D: ≤ф1500mm;
• Precision of cutting: length tolerance: ±1.0mm/2000mm;

• diagonal tolerance: ±1.5mm/2000mm;

• Material of leveling roller: 40Cr, hardness of leveling roller surface: HRC50—54;
• Leveling speed: 0—24m/min;
• Power: 380V three-phase electricity 60Hz;

   Working Flow Chart

   Applications

Steel cutting, metal cutting , metal sheet cut to length,

   Competitive Advantages

   More Machine Pictures
