Steel Structure Floor Deck Roll Forming Machine for Roof Deck, Steel Tile TW-FD1250

Steel Structure Floor Deck Roll Forming Machine for Roof Deck, Steel Tile TW-FD1250

Metal Deck Roll Forming Machine

Floor Deck Roll Forming Machine

Place of Origin:

China

Brand Name:

TECHWELL

Certification:

CE

Model Number:

TW-FD1250

Contact Us

Request A Quote
Product Details
Material Spec:
Galvanized Steel Sheet
Thickness Of Coil Sheet:
0.8-1.2mm
Forming Speed:
10-12m/min
Forming Stations:
About 24 Stations
Controlling System:
PLC
Hydraulic Pressure:
10-12Mpa
Product Description

Steel Structure Floor Deck Roll Forming Machine for Roof Deck, Steel Tile TW-FD1250







  Main Specifications of Floor Deck Roll Forming Machine





  • Material Spec: Galvanized steel sheet
  • Thickness of Coil Sheet: 0.8 --1.2 mm
  • Main Motor Power of Floor decking roll forming machine: 18.5kw
  • Forming Speed: 10--12m/min
  • Hydraulic Station Power: 4kw
  • Quantity of Stands: About 24 groups
  • Hydraulic Pressure: 10~12Mpa
  • Controlling System: PLC
  • Index Error of Length: 10m±1.5mm
  • Total Weight: About 1800kg
  • Voltage: 380V 3 phase 50Hz or at buyers requirement





  Main Components





  • Decoiler ------------------------------------------------- 1 Unit
  • Feeding ------------------------------------------------- 1 Unit
  • Main roll forming machine ----------------------------1 Unit
  • Hydraulic cutting device ------------------------------1 Unit
  • Hydraulic Station ------------------------------------- 1 Unit
  • PLC computer control --------------------------------1 Unit
  • Output table ------------------------------------------- 1 Unit



Steel Structure Floor Deck Roll Forming Machine for Roof Deck, Steel Tile TW-FD1250 0







  Reference Drawings







Steel Structure Floor Deck Roll Forming Machine for Roof Deck, Steel Tile TW-FD1250 1

Steel Structure Floor Deck Roll Forming Machine for Roof Deck, Steel Tile TW-FD1250 2









  Application





Steel floor deck, metal deck, steel deck, metal decking sheet, steel structure floor deck...





Steel Structure Floor Deck Roll Forming Machine for Roof Deck, Steel Tile TW-FD1250 3









  Our Advantage





  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience





  Machine Picture





Steel Structure Floor Deck Roll Forming Machine for Roof Deck, Steel Tile TW-FD1250 4

Steel Structure Floor Deck Roll Forming Machine for Roof Deck, Steel Tile TW-FD1250 5





  Factory Pictures



Steel Structure Floor Deck Roll Forming Machine for Roof Deck, Steel Tile TW-FD1250 6

Steel Structure Floor Deck Roll Forming Machine for Roof Deck, Steel Tile TW-FD1250 7





  Certificate





Steel Structure Floor Deck Roll Forming Machine for Roof Deck, Steel Tile TW-FD1250 8



   Contact Details




Company Wuxi Techwell Machinery Co.,Ltd
Website www.wxtechwell.com
www.cold-rollformingmachine.com
Mobile/Whatsapp 0086-15861597732 (Miss Lemon)
E-Mail/Skype sales@wxtechwell.com
Reference Video Link

https://youtu.be/B6pc2hIRUUM

https://youtu.be/olvLCuRufSc
