Industrial Automatic Hydraulic Decoiler Machine , Sheet Decoiling Machine

China Industrial Automatic Hydraulic Decoiler Machine , Sheet Decoiling Machine supplier
Industrial Automatic Hydraulic Decoiler Machine , Sheet Decoiling Machine supplier Industrial Automatic Hydraulic Decoiler Machine , Sheet Decoiling Machine supplier Industrial Automatic Hydraulic Decoiler Machine , Sheet Decoiling Machine supplier Industrial Automatic Hydraulic Decoiler Machine , Sheet Decoiling Machine supplier

Large Image :  Industrial Automatic Hydraulic Decoiler Machine , Sheet Decoiling Machine

Product Details:

Place of Origin: China
Brand Name: TECHWELL
Certification: CE, ISO
Model Number: TW-DECOILER

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Contact us
Packaging Details: Standard packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 Sets
Contact Now
Detailed Product Description
Decoiler Type: Hydraulic Uncoiling Machine Coil Width: Max. 500mm Or Customized
Uncoiling Speed: 0-12m/min (Adjustable) Pressure Of Hydraulic System: 5.5MPa
Feeding Type: Active Uncoiling, Hydraulic To Expand Weight Capacity: 3/5 Ton

Weight Capacity Of 3 Ton Or 5 Ton Hydraulic Uncoiling / Decoiling Machine With Max Coil Width 500mm





   Main Technical Specifications of Uncoiling Machine



1). Decoiler Type: Hydraulic decoiler

2). Machine Frame: welding structure with shot lasting treatment

3). Description: Put the coil to the mandrel, the hydraulic cylinder will tighten the coil.

4). Start the machine, the motor will drive the mandrel at first, then the steel sheet will be released to the leveling

5)Electric releasing coil, hydraulic expanding, tension

6). Weight capacity: 3/5 Ton

7). Coil width: Max. 500mm, or customized

8). I.D: 400mm-530mm

9). Motor Power: 4.0KW

10). Hydraulic System Power: 3KW

11). Uncoiling speed: 0-20m/min, adjustable

12). Coil car stoke: 2.5m





   Description of Hydraulic Uncoiling Machine



This machine can make stretch coil-deliver coil automatically, the speed of which is same with the forming machine. It is a matching machine for colored steel equipment. In order to save human recourse and lower labor cost, it is better to work with colored steel mould machine and stacker, with which it formed a completely porducing line.



Industrial Automatic Hydraulic Decoiler Machine , Sheet Decoiling Machine





   Competitive Advantages



1. Durable and widely used products

2.Simple to operate when assemble

3.Direct manufacturer, provide with high quality and best price.

4.Provide sample in free.

5.Products and design solution supplied fast and freely

6.Best design oriented for your special requirements





   More Machine Pictures



Industrial Automatic Hydraulic Decoiler Machine , Sheet Decoiling Machine





   Machine Photos With Loading Container



Industrial Automatic Hydraulic Decoiler Machine , Sheet Decoiling Machine
