Light Steel Stud Roll Forming Machine , 5.5 Kw Industrial Metal Roll Forming Machine

China Light Steel Stud Roll Forming Machine , 5.5 Kw Industrial Metal Roll Forming Machine supplier
Light Steel Stud Roll Forming Machine , 5.5 Kw Industrial Metal Roll Forming Machine supplier Light Steel Stud Roll Forming Machine , 5.5 Kw Industrial Metal Roll Forming Machine supplier Light Steel Stud Roll Forming Machine , 5.5 Kw Industrial Metal Roll Forming Machine supplier Light Steel Stud Roll Forming Machine , 5.5 Kw Industrial Metal Roll Forming Machine supplier

Large Image :  Light Steel Stud Roll Forming Machine , 5.5 Kw Industrial Metal Roll Forming Machine

Product Details:

Place of Origin: China
Brand Name: TECHWELL
Certification: CE, ISO
Model Number: TW-ST45

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Contact Now
Detailed Product Description
Shaft Material: 45# High Grade Steel Tempering Treatment (HB220-260) Roller Material: 45# High Grade Steel, And Roller Surface With Hard Chrome ≥ 0.05mm
Forming Speed: 0-15m/min Material Thickness: 0.3-0.7mm, Galvanised Coil
Main Motor Power: 5.5 Kw Hydraulic Motor Power: 4.0 Kw

0.4-0.7mm Forming Material Thickness Light Steel Stud Roll Forming Machine With 2 Lines Of Roof Batten Profiles





   Main Techncial Specifications



1). Material thickness: 0.3-0.7mm, Galvanised coil

2). Material width: depend on customer’s requirement

3). Decoiler Type: manual or automatical type ( depend on customer’s requirement )

4). Main Motor Power: 5.5 Kw

5). Hydraulic Motor Power: 4.0 Kw

6). Forming Station: about 14 ( depend on profile drawing )

7). Material of Roller: High grade 45# forge steel, Polished and coated with 0.05mm Chrome Surface.

8). Main Axis Material: High grade 45#, quenched and heat treatment.

9). Axis Diameter: ¢ 70mm

10). Working Speed: 0-15 m/min

11). Transporting Type: Chain Transmission

12). Heat Treatment of Cutting Blade: HRC 50-60

13). Type of Cutting: Hydraulic cutting

14). Material Of Cutting Blade: C r 12

15). Machine Frame stand: Welded structural steel

16). Electrical Control: PLC Frequency Control System with touch screen

17). PLC: PANASONIC Brand

18). Encoder: OMRON Brand





   Reference Profile Drawing & Finished Sample Sheets



Light Steel Stud Roll Forming Machine , 5.5 Kw Industrial Metal Roll Forming Machine
Light Steel Stud Roll Forming Machine , 5.5 Kw Industrial Metal Roll Forming Machine





   Working Flow Chart



Manual Decoiler → Pinch Feeding → Main Roll Forming → Hydraulic Cutting → Support Table



Light Steel Stud Roll Forming Machine , 5.5 Kw Industrial Metal Roll Forming Machine





   Applications



Metal stud and track, steel stud and track, c stud, u runner, u track, furring channel, roof ceiling batten,



roof truss, c truss, light weight steel truss...





   Competitive Advantages



1. Durable and widely used products

2.Simple to operate when assemble

3.Direct manufacturer, provide with high quality and best price.

4.Provide sample in free.

5.Products and design solution supplied fast and freely

6.Best design oriented for your special requirements





   More Machine Photos



Light Steel Stud Roll Forming Machine , 5.5 Kw Industrial Metal Roll Forming Machine
