Half Round 5in Rainwater Drainpipe Portable Gutter Machine

Large Image : Half Round 5in Rainwater Drainpipe Portable Gutter Machine

Product Details:

Place of Origin:	China
Brand Name:	TECHWELL
Certification:	CE
Model Number:	TW-GM5

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Contact Us
Packaging Details:	Standard packing
Delivery Time:	60-70 working days
Payment Terms:	40% T/T in advance, 60% T/T before shipment
Supply Ability:	20 sets

Contact Now

Detailed Product Description

High Light:

Half Round gutter rolling machine

5in Portable Gutter Machine

Rainwater Drainpipe Portable Gutter Machine

Half Round Gutter Roll Forming Machine For Rainwater Gutter, Half Round Gutter

Main Specifications of Gutter Roll Forming Machine

Material thickness: 0.4-0.8mm
Decoiler: Manaul or hydraulic decoiler
Weight capacity of decoiler: 3 Ton
Forming Station: 16
Main motor power: 3KW
Hydraulic power: 7.5KW
Forming Speed: 0-15m/min
PLC: Panasonic Brand
Cutting blade material: Cr12
Cutting: Hydraulic cutting
Drive: Chain transmission
Electrical Control: PLC Frequency Control System with touch screen
PLC: PANASONIC Brand
Encoder: OMRON Brand
Transducer: PANASONIC Brand

Main Components

Decoiler ---------------------------------------------- 1 Unit
Feeding guide ---------------------------------------- 1 Unit
main roll forming machine ---------------------------- 1 Unit
Hydraulic cutting device ------------------------------ 1 Unit
Hydraulic Station ------------------------------------- 1 Unit
PLC computer control -------------------------------- 1 Unit
Output table ----------------------------------------- 1 Unit

Working Flow

Decoiler--> Coil sheet guiding and feeding --> Roll forming machine --> Cut to length --> Out-put Table

Gutter Profile Drawing

Half Round 5in Rainwater Drainpipe Portable Gutter Machine 0

Applications

Rainwater gutter, k gutter, half round gutter, box gutter ,seamless gutter

Half Round 5in Rainwater Drainpipe Portable Gutter Machine 1

Half Round 5in Rainwater Drainpipe Portable Gutter Machine 2

Our Advantage

High Quality
Reliable
Durable
Reasonable Price
Good after Service
1 Year Warranty
More Than 10 Years Experience

Gutter Machine Pictures

Half Round 5in Rainwater Drainpipe Portable Gutter Machine 3

Half Round 5in Rainwater Drainpipe Portable Gutter Machine 4

Factory Pictures

Half Round 5in Rainwater Drainpipe Portable Gutter Machine 5

Half Round 5in Rainwater Drainpipe Portable Gutter Machine 6

Half Round 5in Rainwater Drainpipe Portable Gutter Machine 7

Half Round 5in Rainwater Drainpipe Portable Gutter Machine 8

Certificate

Half Round 5in Rainwater Drainpipe Portable Gutter Machine 9
