TW-18-271.7-814 Roof Panel Profile Sheet Roll Forming Machine With 14 Forming Stations

China TW-18-271.7-814 Roof Panel Profile Sheet Roll Forming Machine With 14 Forming Stations supplier
TW-18-271.7-814 Roof Panel Profile Sheet Roll Forming Machine With 14 Forming Stations supplier TW-18-271.7-814 Roof Panel Profile Sheet Roll Forming Machine With 14 Forming Stations supplier TW-18-271.7-814 Roof Panel Profile Sheet Roll Forming Machine With 14 Forming Stations supplier TW-18-271.7-814 Roof Panel Profile Sheet Roll Forming Machine With 14 Forming Stations supplier

Large Image :  TW-18-271.7-814 Roof Panel Profile Sheet Roll Forming Machine With 14 Forming Stations

Product Details:

Place of Origin: China
Brand Name: TECHWELL
Certification: CE, BV
Model Number: TW-18-228.5-914

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Contact Now
Detailed Product Description
Profile Type: Roof Panel Shape Profile Decoiler: 5 Ton Weight Capacity
Forming Station: 15 Motor Power: 5.5KW
Hydraulic Power: 3KW Machine Weight: 5.0 Ton



TW-18-271.7-814 Roof Panel Profile Sheet Roll Forming Machine With 14 Forming Stations



   Sumarry of  Roof Panel Roll Forming Machine



1.  Model: TW-18-271.7-814 Roof Panel Profile

2.  Material: Color Steel, Iron, G.I Coils

3.  Material thickness: 0.3-0.8mm

4.  Material width: depend on customer’s requirement

5.  Decoiler Type: manual or automatical type ( depend on customer’s requirement )

6.  Weight Capacity Of Decoiler: 5 Ton

7.  Main Motor Power: 5.5 Kw

8.  Hydraulic Motor Power: 3 Kw

9.  14 Forming Station( depend on profile drawing )

10.  Material of Roller: High grade 45# forge steel, Polished and coated with 0.05mm Chrome Surface.

11.  Main Axis Material: High grade 45#, quenched and heat treatment.

12.  Axis Diameter: ¢ 76mm

13.  Working Speed: 0-15 m/min

14.  Transporting Type: Chain Transmission

15.  Heat Treatment of Cutting Blade: HRC 50-60

16.  Type of Cutting: Hydraulic cutting

17.  Material Of Cutting Blade: C r 12

18.  Heat Treatment of Cutting Blade: HRC 50-60

19.  Machine Frame stand: Welded structural steel

20.  Thickmess of Fame Steel: 18mm

21.  Electrical Control: PLC Frequency Control System with touch screen

22.  PLC: PANASONIC Brand

22.  Encoder: OMRON Brand

23.  Transducer: PANASONIC Brand

24.  Machine Weight: about 5 Ton



   Features of Roof Panel Roll Forming Machine



1.  This Roof Panel Sheet Profile Roll Forming Machine can rollform metal roofing panel sheet. After roll formed by this roof panel sheet roll forming machine, the surface of iron metal roof sheet panel is very smooth and beautiful without any scratch on the surface of profile sheets.

2.  The Roof Panel Sheeting Roll Forming Machine is with fully automatic control system with PLC.

3.  Length, quantity of sheets is adjustable.

4.  Rollforming process: Decoiler, Rollforming, Cut to length.

5.  Easy operation: Key in the length and quantity on the control panel.

6.  1 Year warranty, lifelong time service.

7.  We also can do a custom roll forming machine, we can design machines according to your specifications and profile drawings, all our machines are customized.



   Components of Roo Panel Roll Forming Machine



 Decoiler / Uncoiler  1 Unit
 Feeding Guide  1 Unit
 Roof Roll Forming Machine  1 Unit
 Hydraulic Cutting System                            1 Unit
 Hydraulic Station  1 Unit
 PLC Computer Control Box  1 Unit
 Support Tables  2 Units



   Reference Roof Drawing

TW-18-271.7-814 Roof Panel Profile Sheet Roll Forming Machine With 14 Forming Stations

   Applications



TW-18-271.7-814 Roof Panel Profile Sheet Roll Forming Machine With 14 Forming Stations



Metal roof wall cladding, roof wall panel, Metal Roof sheet, trapezoidal roof metal, trapezoidal roofing, metal roof; steel roof; metal roof wall panel; steel roof wall panel; metal roofing sheet; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding



   TECHWELL Advantage



1.  Copra designing software

2.  5-8 technicians every month specially do international installation and debugging

3.  High Quality

4.  Reasonable Price

5.  Good after Service

6.  1 Year Warranty

3.  More Than 10 Years Experience



   Roof Panel Roll Forming Machine Photos



TW-18-271.7-814 Roof Panel Profile Sheet Roll Forming Machine With 14 Forming Stations

TW-18-271.7-814 Roof Panel Profile Sheet Roll Forming Machine With 14 Forming Stations
