PBU Metal Roof / Wall Panel Roll Forming Machine For PBU, U Panels

China PBU Metal Roof / Wall Panel Roll Forming Machine For PBU, U Panels supplier
PBU Metal Roof / Wall Panel Roll Forming Machine For PBU, U Panels supplier PBU Metal Roof / Wall Panel Roll Forming Machine For PBU, U Panels supplier PBU Metal Roof / Wall Panel Roll Forming Machine For PBU, U Panels supplier PBU Metal Roof / Wall Panel Roll Forming Machine For PBU, U Panels supplier

Large Image :  PBU Metal Roof / Wall Panel Roll Forming Machine For PBU, U Panels

Product Details:

Place of Origin: China
Brand Name: TECHWELL
Certification: CE, BV
Model Number: TW-PBU

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Contact Now
Detailed Product Description
Profile: PBU Roof Profile Forming Station: 18
Shaft Diameter: 76mm Roller Material: 45# Steel, Hard Chrome
Motor Power: 7.5KW Cutting Power: 3KW



PBU Metal Roof / Wall Panel Roll Forming Machine For PBU, U Panels



   Main Specifications of PBU Roof Wall Panel Roll Forming Machine



  • Model: R, PBU, PBR, IBR Roof Panel Profile
  • Material: Color Steel, Iron, G.I Coils
  • Material thickness: 0.3-0.8mm
  • Material width: depend on customer’s requirement
  • Decoiler Type: manual or automatical type ( depend on customer’s requirement )
  • Weight Capacity Of Decoiler: 5 Ton
  • Main Motor Power: 5.5 Kw
  • Hydraulic Motor Power: 3 Kw
  • 18 Forming Station( depend on profile drawing )
  • Material of Roller: High grade 45# forge steel, Polished and coated with 0.05mm Chrome Surface.
  • Main Axis Material: High grade 45#, quenched and heat treatment.
  • Axis Diameter: ¢ 76mm
  • Forming Speed of Metal roof wall panel roll forming machine: 0-15 m/min
  • Transporting Type: Chain Transmission
  • Heat Treatment of Cutting Blade: HRC 50-60
  • Cutting type of roof wall panel forming machine: Hydraulic cutting
  • Material Of Cutting Blade: C r 12
  • Heat Treatment of Cutting Blade: HRC 50-60
  • Machine Frame stand: Welded structural steel
  • Thickmess of Fame Steel: 18mm
  • Electrical Control: PLC Frequency Control System with touch screen
  • PLC: PANASONIC Brand
  • Encoder: OMRON Brand
  • Transducer: PANASONIC Brand
  • Machine Weight: about 5 Ton



   Componnets of PBU Roof Panel Roll Forming Machine





 Decoiler / Uncoiler  1 Unit
 Feeding Guide  1 Unit
 Wall Panel Roof Roll Forming Machine  1 Unit
 Hydraulic Cutting System                            1 Unit
 Hydraulic Station  1 Unit
 PLC Computer Control Box  1 Unit
 Support Tables  2 Units



   Characteristic of PBU Roof Panel Roll Forming Machine

  • This Roof Wall Panel Roll Forming Machine can rollform metal roofing wall panel. After roll formed by this roof wall panel sheet roll forming machine, the surface of iron roof wall panel is very smooth and beautiful without any scratch on the surface of profile sheets.
  • The Roof Wall Panel Sheet Roll Forming Machine is with fully automatic control system with PLC.
  • Length, quantity of sheets is adjustable.
  • Rollforming process: Uncoiler, Rollforming, Cut to length.
  • Easy operation: Key in the length and quantity on the control panel.
  • 1 Year warranty, lifelong time service.
  • We also can do a custom roll forming machine, we can design machines according to your specifications and profile drawings, all our machines are customized.



   Process Working Flow of PBU Roof Panel Roll Forming Machine



Decoiler ---> Feeding ---> Main Roof Wall Panel Roll Forming ---> Cutting To Length ---> Support Table



   Reference Roof Wall Panel Drawings



PBU Metal Roof / Wall Panel Roll Forming Machine For PBU, U Panels



   Applications



Metal Roof Wall Panel, Metal roof wall cladding, roof wall panel, Metal Roof sheet, trapezoidal roof metal, trapezoidal roofing, metal roof; steel roof; metal roof wall panel; steel roof wall panel; metal roofing sheet; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding



   TECHWELL Advantage



  • High Quality
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience
  • Copra Design Software

   Pictures of PBU Roof Wall Panel Roll Forming Machine



PBU Metal Roof / Wall Panel Roll Forming Machine For PBU, U Panels

PBU Metal Roof / Wall Panel Roll Forming Machine For PBU, U Panels
