C8 Wall Panel Sheet Roof Roll Forming Machine With 0.3mm - 0.8mm Thickness

C8 Wall Panel Sheet Roof Roll Forming Machine With 0.3mm - 0.8mm Thickness

Roof Sheet Roll Forming Machine

roof panel roll forming machine

Place of Origin:

China

Brand Name:

TECHWELL

Certification:

CE, BV

Model Number:

C8

Contact Us

Request A Quote
Product Details
Profile:
C8 Shape Profile
Coil Type:
Color Stee, PPGI, Aluminium
Coi LThickness:
0.3-0.8mm
Forming Station:
According To Profile
Shaft Diameter:
76mm
Roller Material:
45# Steel With 0.05mm Hard Chrome
Product Description



C8 Wall Panel Sheet Roof Roll Forming Machine With  0.3mm - 0.8mm Thickness



   Components of Wal Panel Roll Forming Machine



 Decoiler / Uncoiler  1 Unit
 Feeding Guide  1 Unit
 Wall Panel Roll Forming Machine  1 Unit
 Hydraulic Cutting System                            1 Unit
 Hydraulic Station  1 Unit
 PLC Computer Control Box  1 Unit
 Support Tables  2 Units



   Characteristic of Wall Panel Roll Forming Machine

  1. This Wall Panel Roll Forming Machine can rollform metal roofing wall sheet. After roll formed by this wall panel sheet roll forming machine, the surface of iron roof wall panel is very smooth and beautiful without any scratch on the surface of profile sheets.
  2. The Roof Wall Panel Sheet Roll Forming Machine is with fully automatic control system with PLC.
  3. Length, quantity of sheets is adjustable.
  4. Rollforming process: Decoiler, Rollforming, Cut to length.
  5. Easy operation: Key in the length and quantity on the control panel.
  6. 1 Year warranty, lifelong time service.
  7. We also can do a custom roll forming machine, we can design machines according to your specifications and profile drawings, all our machines are customized.



   Technical Specifications of Wall Panel Roll Forming Machine



 Item  C8 Wall Panel Roll Forming Machine
 Coil Material  Thickness  0.3-0.8mm
 Coil width  Custom-made, 1000mm or 1200mm or 1250mm
 Yield Strength             250-350 Mpa
 Material  PPGI, Color Steel, GI.
 Decoiler / Uncoiler  Uncoiler Type  Manual or Hydraulic or Auto Type
 Coil Width  Max. 1250mm
 I.D  508-610mm
 O.D  Max. 1500mm
 Wall Panel Roll Forming Machine    Forming Stations  16-18 Stations ( Depend on Profiles )
 Roller material   45# steel, surface coated with 0.05mm hard  chrome
 Diameter of shaft   76mm
 Shaft material  High grade 45# steel
 Drive type  Chain transmission
 Forming speed  0-15m/min
 Main power  5.5KW
 Cutting Device                        Cutting type  Hydraulic cutting
 Cutting Die Material  Cr12Mov steel, HRC58-62
 Cutting power  3KW
 CuttingTolerance  10m+/-1.5mm
 Encoder  OMRON Brand
 PLC Electrical Control System  PLC                                    PANASONIC Brand
 Inverter  YASKAWA Brand
 Touch screen  PANASONICE
 Operation type  Touch screen & Button
 Hydraulic Station  Hydraulic station  Famous Chinese brand
 Runout Tables  Table type  Simple nonpower type
 Function  To support the finished panels



   Wall Panel Drawing



C8 Wall Panel Sheet Roof Roll Forming Machine With  0.3mm - 0.8mm Thickness 0



   Pictures of Wal Panel Roll Forming Machine



C8 Wall Panel Sheet Roof Roll Forming Machine With  0.3mm - 0.8mm Thickness 1

C8 Wall Panel Sheet Roof Roll Forming Machine With  0.3mm - 0.8mm Thickness 2

C8 Wall Panel Sheet Roof Roll Forming Machine With  0.3mm - 0.8mm Thickness 3



   Applications



Wall Panel, Wall Sheets, Metal roof wall cladding, roof wall panel, Metal Roof sheet, trapezoidal roof metal, trapezoidal roofing, metal roof; steel roof; metal roof wall panel; steel roof wall panel; metal roofing sheet; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding



   TECHWELL  Advantage



  • Copra designing software
  • 5-8 technicians every month specially do international installation and debugging
  • High Quality
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience



C8 Wall Panel Sheet Roof Roll Forming Machine With  0.3mm - 0.8mm Thickness 4
