Name: Chromadek IBR Roof Panel Roll Forming Machine With 0 - 15 m/min Working Speed
Brand: Wuxi Techwell Machinery Co., Ltd
SKU: TW-RWM
Availability: InStock

Home > products > Roof Roll Forming Machine >

Chromadek IBR Roof Panel Roll Forming Machine With 0 - 15 m/min Working Speed

Roof Sheet Roll Forming Machine

roof panel roll forming machine

Place of Origin:

China

Brand Name:

TECHWELL

Certification:

Model Number:

TW-RWM

Request A Quote

Chromadek IBR Roof Panel Roll Forming Machine With 0 - 15 m/min Working Speed

Product Details

Forming Speed:

0-20m/min

Material Thickness:

0.3-0.7mm

Cutting Power:

3.0KW

Cutter Material:

CR12Mov Mold Steel, With Quench Treatment

Forming Roller Material:

45# Steel, Coated With Hard Chrome 0.05mm

Forming Roller Stations:

22-24 Forming Stations

Corrugated Profile Roll Forming Machine , Corrugated Sheet Making Machine With PLC Control System

Get Best Price

PLC Frequency Control Metal Roof Panel Roll Forming Machine With Color Steel , PPGI Raw Material

Get Best Price

IBR Roofing Sheet Roll Forming Machine / IBR Panel Forming Machine For Making Roof Wall Cladding

Get Best Price

Video

Iron Metal Roof Sheet Roll Forming Machine With Manual Or Hydraulic Uncoiler

Get Best Price

86-510-83133431

monica@wxtechwell.com

86-510-83133431

Contact Now

Product Description

Chromadek IBR Roof Panel Roll Forming Machine With 0 - 15 m/min Working Speed

Main Specifications of IBR Roof Panel Roll Forming Machine

Item	IBR Roof Panel Roll Forming Machine
Coil Material	Thickness	0.3-0.8mm
	Coil width	Custom-made, 925mm or 940mm
	Yield Strength	250-350 Mpa
	Material	PPGI, Color Steel, GI.
Decoiler / Uncoiler	Decoiler Type	Manual or Hydraulic or Auto Type
	Coil Width	Max. 1250mm
	I.D	508-610mm
	O.D	Max. 1500mm
IBR Roof Panel Roll FormingMachine	Forming Stations	18 Stations ( Depend on Profiles )
	Roller material	45# steel, surface coated with 0.05mm hard chrome
	Diameter of shaft	76mm
	Shaft material	High grade 45# steel
	Drive type	Chain transmission
	Forming speed	0-15m/min
	Main power	5.5KW
Cutting Device	Cutting type	Hydraulic cutting
	Cutting Die Material	Cr12Mov steel, HRC58-62
	Cutting power	3KW
	CuttingTolerance	10m+/-1.5mm
	Encoder	OMRON Brand
Electrical Control System	PLC	PANASONIC Brand
	Inverter	YASKAWA Brand
	Touch screen	PANASONICE
	Operation type	Touch screen & Button
Hydraulic Station	Hydraulic station	Famous Chinese brand
Runout Table	Table type	Simple nonpower type
Runout Table	Function	To support the finished panels

Main Components of IBR Panel Roll Forming Machine

Decoiler / Uncoiler	1 Unit
Feeding Guide	1 Unit
IBR Roof Panel Roll Forming Machine	1 Unit
Hydraulic Cutting Part	1 Unit
Hydraulic Station	1 Unit
PLC Computer Control Box	1 Unit
Runout Table	2 Units

Reference IBR Roof Drawings

Chromadek IBR Roof Panel Roll Forming Machine With 0 - 15 m/min Working Speed 0

Chromadek IBR Roof Panel Roll Forming Machine With 0 - 15 m/min Working Speed 1

Chromadek IBR Roof Panel Roll Forming Machine With 0 - 15 m/min Working Speed 2

Applications

IBR Roof Panel, IBR Sheets, IBR Roofing, IBR Sheeting, Trapezoidal roof panel, trapezoidal sheet, trapezoidal roof metal, trapezoidal roofing, metal roof; steel roof; metal roof wall panel; steel roof wall panel; metal roofing sheet; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding

Our Advantage

Copra designing software
5-8 technicians every month specially do international installation and debugging
High Quality
Reasonable Price
Good after Service
1 Year Warranty
More Than 10 Years Experience

IBR Roof Panel Forming Machine Pictures

Chromadek IBR Roof Panel Roll Forming Machine With 0 - 15 m/min Working Speed 3
