Product Description

Color Steel Trapezoidal Panel Profile Roll Forming Machine With Panasonic PLC

Main Specifications of Trapezoidal Panel Profile Roll Forming Machine

Item	Trapezoidal Panel Profile Roll Forming Machine
Coil Material	Thickness	0.3-0.8mm
	Coil width	Custom-made, 1000 or 1200 or 1250mm
	Yield Strength	250-350 Mpa
	Material	PPGI, Color Steel, GI.
Decoiler / Uncoiler	Uncoiler Type	Manual or Hydraulic or Auto Type
	Coil Width	Max. 1250mm
	I.D	508-610mm
	O.D	Max. 1500mm
Trapezoidal Panel Roll Forming Machine	Forming Stations	16-18 Stations ( Depend on Profiles )
	Roller material	45# steel, surface coated with 0.05mm hard chrome
	Diameter of shaft	76mm
	Shaft material	High grade 45# steel
	Drive type	Chain transmission
	Forming speed	0-15m/min
	Main power	5.5KW
Cutting Device	Cutting type	Hydraulic cutting
	Cutting Die Material	Cr12Mov steel, HRC58-62
	Cutting power	3KW
	CuttingTolerance	10m+/-1.5mm
	Encoder	OMRON Brand
PLC Electrical Control System	PLC	PANASONIC Brand
	Inverter	YASKAWA Brand
	Touch screen	PANASONICE
	Operation type	Touch screen & Button
Hydraulic Station	Hydraulic station	Famous Chinese brand
Runout Tables	Table type	Simple nonpower type
Runout Tables	Function	To support the finished panels

Characteristic of Trapezoidal Panel Roll Forming Machine

This Trapezoidal Panel Roll Forming Machine can rollform metal roofing sheet. After roll formed by this trapezoidal roof panel roll forming machine, the surface of metal trapezoidal roofing is very smooth and beautiful without any scratch on the surface of roofing sheets.
The Trapezoidal Roof Panel Roll Forming Machine is with fully automatic control system with PLC.
Length, quantity of sheets is adjustable.
Rollforming process: Uncoiler, Rollforming, Cut to length.
1 Year warranty, lifelong time service.
Easy operation: Key in the length and quantity on the control panel.
We also can do a custom roll forming machine, we can design machines according to your specifications and profile drawings, all our machines are customized.

Composition of This Trapezoidal Panel Forming Machine

Decoiler / Uncoiler	1 Unit
Feeding Guide	1 Unit
Trapezoidal Panel Roll Forming Machine	1 Unit
Hydraulic Cutting System	1 Unit
Hydraulic Station	1 Unit
PLC Computer Control Box	1 Unit
Support Tables	2 Units

Reference Trapezoidal Profile Drawings

Color Steel Trapezoidal Panel Profile Roll Forming Machine With Panasonic PLC 0

Color Steel Trapezoidal Panel Profile Roll Forming Machine With Panasonic PLC 1

Machine Pictures

Color Steel Trapezoidal Panel Profile Roll Forming Machine With Panasonic PLC 2
