10 - 12Mpa Hydraulic Pressure Metal Deck Roll Forming Machine for 0.8 - 1.2 mm Thickness

China 10 - 12Mpa Hydraulic Pressure Metal Deck Roll Forming Machine for 0.8 - 1.2 mm Thickness supplier
10 - 12Mpa Hydraulic Pressure Metal Deck Roll Forming Machine for 0.8 - 1.2 mm Thickness supplier 10 - 12Mpa Hydraulic Pressure Metal Deck Roll Forming Machine for 0.8 - 1.2 mm Thickness supplier 10 - 12Mpa Hydraulic Pressure Metal Deck Roll Forming Machine for 0.8 - 1.2 mm Thickness supplier 10 - 12Mpa Hydraulic Pressure Metal Deck Roll Forming Machine for 0.8 - 1.2 mm Thickness supplier

Large Image :  10 - 12Mpa Hydraulic Pressure Metal Deck Roll Forming Machine for 0.8 - 1.2 mm Thickness

Product Details:

Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-FD1250

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Contact Now
Detailed Product Description
Thickness Range: 0.8-1.5mm Forming Stations: About 22 Stations
Roller Material: Gcr15 Steel, Quenched And Heated Process, HRC58-62 Main Power: 22KW

10 - 12Mpa Hydraulic Pressure Metal Deck Roll Forming Machine for 0.8 - 1.2 mm Thickness






  Main Specifications of Metal Deck Roll Forming Machine



Suitable Material Thickness of coil sheet 0.8-1.5mm
Coil width Custom-made, 1000mm or 1200mm or 1250mm
Yield strength 250-350Mpa
Material Galvanized steel sheet
Decoiler / Uncoiler Uncoiler type Manual or Hydraulic or Auto Type
Coil width Max.1250mm
I.D 508-610mm
O.D Max.1500mm
Floor Deck Roll Forming Machine Forming Stations about 22 stations (Depend on final design)
Roller material Gcr15 steel, quenched and heated process, HRC58-62
Drive type Chain transmission
Forming speed 10-15m/min
Main power 22KW
Cutting Device Cutting type Hydraulic cutting
Cutting die material Cr12Mov steel, HRC58-62
Cutting tolerance +/-1.5mm
Encoder OMRON Brand
PLC Electrical Control Board PLC PANASONIC Brand
Inverter YASKAWA Brand
Touch screen PANASONIC
Operation type Touch screen & Button
Hydraulic Station Hydraulic Station Famous Chinese Brand
Hydraulic power 4.0KW
Hydraulic pressure 10-12Mpa





  Main Components





  • Decoiler ------------------------------------------------- 1 Unit
  • Feeding ------------------------------------------------- 1 Unit
  • Main roll forming machine ----------------------------1 Unit
  • Hydraulic cutting device ------------------------------1 Unit
  • Hydraulic Station ------------------------------------- 1 Unit
  • PLC computer control --------------------------------1 Unit
  • Output table ------------------------------------------- 1 Unit





  Reference Drawings







10 - 12Mpa Hydraulic Pressure Metal Deck Roll Forming Machine for 0.8 - 1.2 mm Thickness







  Application





Steel floor deck, metal deck, steel deck, metal decking sheet, steel structure floor deck...





10 - 12Mpa Hydraulic Pressure Metal Deck Roll Forming Machine for 0.8 - 1.2 mm Thickness









  Our Advantage





  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience





  Machine Picture



10 - 12Mpa Hydraulic Pressure Metal Deck Roll Forming Machine for 0.8 - 1.2 mm Thickness
