Galvanized Plate / Steel Corrugated Sheet Roll Forming Machine for For Wall Panel

China Galvanized Plate / Steel Corrugated Sheet Roll Forming Machine for For Wall Panel supplier
Galvanized Plate / Steel Corrugated Sheet Roll Forming Machine for For Wall Panel supplier Galvanized Plate / Steel Corrugated Sheet Roll Forming Machine for For Wall Panel supplier Galvanized Plate / Steel Corrugated Sheet Roll Forming Machine for For Wall Panel supplier Galvanized Plate / Steel Corrugated Sheet Roll Forming Machine for For Wall Panel supplier

Large Image :  Galvanized Plate / Steel Corrugated Sheet Roll Forming Machine for For Wall Panel

Product Details:

Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-SILO

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 100-120 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Contact Now
Detailed Product Description

Galvanized Plate / Steel Corrugated Sheet Roll Forming Machine for For Wall Panel





  Main Specifications of Steel Corrugated Sheet Roll Forming Machine



  • Suitable material: Galvanized sheet, Zinc Alumina sheet
  • Material yield strength: 310Mpa
  • Material thickness: 2.5-4.0mm
  • Max. Feeding coil width: 1250mm
  • Machine working speed: 4-8m//min
  • Forming station: approx 18 stations
  • Size of roll shaft:  Ф120mm
  • Roller material: GCr15, quenching HRC 58-62 °
  • Total power: approx 180KW
  • Power supply: AC440V+/-10%, 50Hz, 3 Phase
  • Whole line dimention: about 35M X 4.5M ( L X W )
  • Installation height: 4.5m
  • Total weith of machine: approx 70 tons





  Working Flow


Loading coil car  ->  Un-coiler  ->  guiding device ->  feeder  ->  leveller  ->  shear roll former  ->  hydraulic press  -



>  curving  -> hydraulic cutting  ->  stacker  ->  PLC control





  Reference Drawing



Galvanized Plate / Steel Corrugated Sheet Roll Forming Machine for For Wall Panel

Galvanized Plate / Steel Corrugated Sheet Roll Forming Machine for For Wall Panel

Galvanized Plate / Steel Corrugated Sheet Roll Forming Machine for For Wall Panel





  Application



Steel silo corrugated sheet, steel silo corrugated panel, silo wall sheet, silo corrugated wall sheet, silo wall panel,



silo corrugated wall panel, silo side panel, steel corrugated sheet, steel corrugated wall panel, steel corrugated



panel



Galvanized Plate / Steel Corrugated Sheet Roll Forming Machine for For Wall Panel

Galvanized Plate / Steel Corrugated Sheet Roll Forming Machine for For Wall Panel





  Our Advantage

  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience



  Machine Pictures



Galvanized Plate / Steel Corrugated Sheet Roll Forming Machine for For Wall Panel





   Workshop Machine Pictures



 Galvanized Plate / Steel Corrugated Sheet Roll Forming Machine for For Wall Panel
