2.0 - 4.0mm Thickness Corrugated Steel Sheet Roll Forming Machine For Silo Wall Panel

2.0 - 4.0mm Thickness Corrugated Steel Sheet Roll Forming Machine For Silo Wall Panel

corrugated sheet making machine

corrugated sheet forming machine

Place of Origin:

China

Brand Name:

TECHWELL

Certification:

CE

Model Number:

TW-SILO

Contact Us

Request A Quote
Product Details
Product Description





2.0 - 4.0mm Thickness Corrugated Steel Sheet Roll Forming Machine For Silo Wall Panel







  Main Specifications





  • Suitable material: Galvanized sheet, Zinc Alumina sheet
  • Material yield strength: 310Mpa
  • Material thickness: 2.5-4.0mm
  • Max. Feeding coil width: 1250mm
  • Machine working speed: 4-8m//min
  • Forming station: approx 18 stations
  • Size of roll shaft:  Ф120mm
  • Roller material: GCr15, quenching HRC 58-62 °
  • Total power: approx 180KW
  • Power supply: AC440V+/-10%, 50Hz, 3 Phase
  • Whole line dimention: about 35M X 4.5M ( L X W )
  • Installation height: 4.5m
  • Total weith of machine: approx 70 tons







  Working Flow




Loading coil car  ->  Un-coiler  ->  guiding device ->  feeder  ->  leveller  ->  shear roll former  ->  hydraulic press  ->  curving  -> hydraulic cutting  ->  stacker  ->  PLC control









  Reference Drawing







2.0 - 4.0mm Thickness Corrugated Steel Sheet Roll Forming Machine For Silo Wall Panel 0

2.0 - 4.0mm Thickness Corrugated Steel Sheet Roll Forming Machine For Silo Wall Panel 1

2.0 - 4.0mm Thickness Corrugated Steel Sheet Roll Forming Machine For Silo Wall Panel 2

2.0 - 4.0mm Thickness Corrugated Steel Sheet Roll Forming Machine For Silo Wall Panel 3









  Application





Steel silo corrugated sheet, steel silo corrugated panel, silo wall sheet, silo corrugated wall sheet, silo wall panel, silo corrugated wall panel, silo side panel, steel corrugated sheet, steel corrugated wall panel, steel corrugated panel





2.0 - 4.0mm Thickness Corrugated Steel Sheet Roll Forming Machine For Silo Wall Panel 4

2.0 - 4.0mm Thickness Corrugated Steel Sheet Roll Forming Machine For Silo Wall Panel 5







  Our Advantage



  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience







  Machine Pictures







2.0 - 4.0mm Thickness Corrugated Steel Sheet Roll Forming Machine For Silo Wall Panel 6

2.0 - 4.0mm Thickness Corrugated Steel Sheet Roll Forming Machine For Silo Wall Panel 7

2.0 - 4.0mm Thickness Corrugated Steel Sheet Roll Forming Machine For Silo Wall Panel 8









  Factory Pictures







2.0 - 4.0mm Thickness Corrugated Steel Sheet Roll Forming Machine For Silo Wall Panel 9

2.0 - 4.0mm Thickness Corrugated Steel Sheet Roll Forming Machine For Silo Wall Panel 10

2.0 - 4.0mm Thickness Corrugated Steel Sheet Roll Forming Machine For Silo Wall Panel 11









2.0 - 4.0mm Thickness Corrugated Steel Sheet Roll Forming Machine For Silo Wall Panel 12







  Certificate





2.0 - 4.0mm Thickness Corrugated Steel Sheet Roll Forming Machine For Silo Wall Panel 13
