Downpipe Roll Forming Machine for Rainwater Downpipe, Rainspout, Water Pipe, Drainpipe

Name: Downpipe Roll Forming Machine for Rainwater Downpipe, Rainspout, Water Pipe, Drainpipe
Brand: TECHWELL
SKU: TW-DP100
Price: 1.00 USD
Availability: InStock
Rating: 5 (159 reviews)

Large Image : Downpipe Roll Forming Machine for Rainwater Downpipe, Rainspout, Water Pipe, Drainpipe

Product Details:

Place of Origin:	China
Brand Name:	TECHWELL
Certification:	CE
Model Number:	TW-DP100

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Contact Us
Packaging Details:	Standard packing
Delivery Time:	70-80 working days
Payment Terms:	40% T/T in advance, 60% T/T before shipment
Supply Ability:	20 sets

Contact Now

Detailed Product Description

Coil Thickness Range:	0.4-0.6mm	Forming Stations:	About 20 Stations (Depend On Profile)
Working Speed:	0-15m/min (excluding Cutting Time)	Forming Material:	PPGI, Aluminum
Shaft Diameter:	75mm	Roller Material:	High Grade 45#, Polished And Coated With 0.05mm Chrome Surface
High Light:	Down Pipe Roll Forming Machine , Round Downspout Machine

Downpipe Roll Forming Machine for Rainwater Downpipe, Rainspout, Water Pipe, Drainpipe

Main Specifications

Main motor power: 7.5Kw
Number of forming station: About 20
Forming speed of downpipe roll forming machine: 6-12m/min
Voltage: 380 V, 3 Phase 50Hz ( or depend on customer’s requirement )
Dimension of machine: About 12000mm*1100mm*1200mm
Machine wight: about 12 Ton
Material of Axis: High grade 45# steel
Diameter of Axis: φ75mm
Material of Roller: High grade 45#, polished and coated with 0.05mm Chrome Surface.
Materical of Machine Frame: A3 Steel, thickness 18mm
Electrical Control: PLC Frequency Control System with touch screen
PLC: PANASONIC Brand
Encoder: OMRON Brand
Transducer: PANASONIC Brand

Reference Rainspout Drawing

Downpipe Roll Forming Machine for Rainwater Downpipe, Rainspout, Water Pipe, Drainpipe 0

Downpipe Roll Forming Machine for Rainwater Downpipe, Rainspout, Water Pipe, Drainpipe 1

Main Components

Decoiler -------------------------------------------- -- 1 Unit
Feeding guide ---------------------------------------- 1 Unit
main roll forming machine ------------------------- 1 Unit
Hydraulic cutting device ---------------------------- 1 Unit
Hydraulic Station ------------------------------------- 1 Unit
PLC computer control ------------------------------ 1 Unit
Output table ------------------------------------------- 1 Unit
Elbow machine --------------------------------------- 1 Unit

Working Flow

Decoiler--> Coil sheet guiding and feeding --> Roll forming machine with safty guard--> Tighten Device -> Cut to

length --> Out-put Table --> Curving machine

Applications

Rainwater downpipe, downspout, rainspout, water pipe, drainpipe

Downpipe Roll Forming Machine for Rainwater Downpipe, Rainspout, Water Pipe, Drainpipe 2

Our Advantage

High Quality
Reliable
Durable
Reasonable Price
Good after Service
1 Year Warranty
More Than 10 Years Experience

Machine Pictures

Downpipe Roll Forming Machine for Rainwater Downpipe, Rainspout, Water Pipe, Drainpipe 3

Contact Details

Item	Contact Methods
Contact Person	Lemon
E-mail / Skype	sales@wxtechwell.com
Tel / Whatsapp	+86-15861597732
Website	https://www.wxtechwell.com www.cold-rollformingmachine.com
Reference Video	https://youtu.be/gkBqhWdUwmI https://youtu.be/T7n-n9DOa9w
