Custom Round Downpipe Roll Forming Machine / Downspout Machine for Drainpipe

Name: Custom Round Downpipe Roll Forming Machine / Downspout Machine for Drainpipe
Brand: TECHWELL
SKU: TW-DP100
Price: 1.00 USD
Availability: InStock
Rating: 4.8 (182 reviews)

Large Image : Custom Round Downpipe Roll Forming Machine / Downspout Machine for Drainpipe

Product Details:

Place of Origin:	China
Brand Name:	TECHWELL
Certification:	CE
Model Number:	TW-DP100

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Contact Us
Packaging Details:	Standard packing
Delivery Time:	70-80 working days
Payment Terms:	40% T/T in advance, 60% T/T before shipment
Supply Ability:	20 sets

Contact Now

Detailed Product Description

High Light:

Round Downspout Machine

Downspout Roll Forming Machine

Custom Round Downpipe Roll Forming Machine / Downspout Machine for Drainpipe

Main Specifications of Downpipe Roll Forming Machine

Main motor power: 7.5Kw
Number of forming station: About 20
Forming speed of downpipe forming machine: 6-12m/min
Voltage: 380 V, 3 Phase 50Hz ( or depend on customer’s requirement )
Dimension of machine: About 12000mm*1100mm*1200mm
Machine wight: about 12 Ton
Material of Axis: High grade 45# steel
Diameter of Axis: φ75mm
Material of Roller: High grade 45#, polished and coated with 0.05mm Chrome Surface.
Materical of Machine Frame: A3 Steel, thickness 18mm
Electrical Control: PLC Frequency Control System with touch screen
PLC: PANASONIC Brand
Encoder: OMRON Brand
Transducer: PANASONIC Brand

Reference Rainspout Drawing

Custom Round Downpipe Roll Forming Machine / Downspout Machine for Drainpipe 0

Custom Round Downpipe Roll Forming Machine / Downspout Machine for Drainpipe 1

Custom Round Downpipe Roll Forming Machine / Downspout Machine for Drainpipe 2

Main Components

Decoiler ---------------------------------------------- 1 Unit
Feeding guide ---------------------------------------- 1 Unit
main roll forming machine ---------------------------- 1 Unit
Hydraulic cutting device ------------------------------ 1 Unit
Hydraulic Station ------------------------------------- 1 Unit
PLC computer control -------------------------------- 1 Unit
Output table ----------------------------------------- 1 Unit
Elbow machine --------------------------------------- 1 Unit

Working Flow

Decoiler--> Coil sheet guiding and feeding --> Roll forming machine with safty guard--> Tighten Device -> Cut to length --> Out-put Table --> Curving machine

Custom Round Downpipe Roll Forming Machine / Downspout Machine for Drainpipe 3

Applications

Rainwater downpipe, downspout, rainspout, water pipe, drainpipe

Custom Round Downpipe Roll Forming Machine / Downspout Machine for Drainpipe 4

Custom Round Downpipe Roll Forming Machine / Downspout Machine for Drainpipe 5

Our Advantage

High Quality
Reliable
Durable
Reasonable Price
Good after Service
1 Year Warranty
More Than 10 Years Experience

Video of Round Downpipe Forming Machine

Machine Pictures

Custom Round Downpipe Roll Forming Machine / Downspout Machine for Drainpipe 6

Custom Round Downpipe Roll Forming Machine / Downspout Machine for Drainpipe 7

Custom Round Downpipe Roll Forming Machine / Downspout Machine for Drainpipe 8

Factory Pictures

Custom Round Downpipe Roll Forming Machine / Downspout Machine for Drainpipe 9

Custom Round Downpipe Roll Forming Machine / Downspout Machine for Drainpipe 10

Custom Round Downpipe Roll Forming Machine / Downspout Machine for Drainpipe 11

Custom Round Downpipe Roll Forming Machine / Downspout Machine for Drainpipe 12

Certificate

Custom Round Downpipe Roll Forming Machine / Downspout Machine for Drainpipe 13
