Custom 5 - 20 Ton Curving Machine Hydraulic Decoiler With Pneumatic Damp Pressing Arm

Custom 5 - 20 Ton Curving Machine Hydraulic Decoiler With Pneumatic Damp Pressing Arm

Roll Former Machine

Sheet Metal Roll Forming Machines

Place of Origin:

China

Brand Name:

TECHWELL

Certification:

CE

Model Number:

TW-DECOILER

Contact Us

Request A Quote
Product Details
Product Description





Custom 5 - 20 Ton Curving Machine Hydraulic Decoiler With Pneumatic Damp Pressing Arm



   Description



Decoilers also known as uncoilers, are designed and engineered by Machinery for supporting coil and a smooth efficient unreeling of coil material into a roll forming production line with a load capacity from 5 Ton up to 20 ton. According to the power supply difference, there are manual version, motor version, and hydraulic version.





  Main Specifications







  • Active uncoiling, hydraulic to expand
  • Weight capacity: 5/7/10/15 Ton
  • Width of coil: 1500mm Max.
  • Inner diameter: 508-610mm
  • Outer diameter: 1300mm
  • Material of main shaft: 40Cr
  • Outline dimentision: about 3110x1650x1780mm
  • Hydraulic motor power: 2.5KW
  • Pneumatic damp pressing arm
  • Uncoiling speed: 0-15m/min
  • Capacity of hydraulic station: 40L
  • Hydraulic system pressure: 6.3Mpa
  • Coil car stoke: 2.5m
  • Pressure of hydraulic system:6.3Mpa
  • Weight of coil beared by car: 5-15 Ton





Custom 5 - 20 Ton Curving Machine Hydraulic Decoiler With Pneumatic Damp Pressing Arm 0







  Our Advantages





  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience



   More Machine Pictures



Custom 5 - 20 Ton Curving Machine Hydraulic Decoiler With Pneumatic Damp Pressing Arm 1
