5 Ton Hydraulic Auto Decoiler / Uncoiler Curving Machine With Uncoiling Speed 0 - 15m/min

Large Image : 5 Ton Hydraulic Auto Decoiler / Uncoiler Curving Machine With Uncoiling Speed 0 - 15m/min

Product Details:

Place of Origin:	China
Brand Name:	TECHWELL
Certification:	CE
Model Number:	TW-DECOILER

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Contact Us
Packaging Details:	Standard packing
Delivery Time:	55-65 working days
Payment Terms:	40% T/T in advance, 60% T/T before shipment
Supply Ability:	20 sets

Contact Now

Detailed Product Description

Weight Capacity:	5/7/10/15 Ton	Decoiler Type:	Hydraulic Decoiler
Uncloiling Speed:	0-15m/min	I.D:	508-610MM
Outer Diameter:	1300MM	Hydraulic Motor Power:	2.5Kw
High Light:	Sheet Metal Roll Forming Machines , Roll Forming Equipment

5 Ton Hydraulic Auto Decoiler / Uncoiler Curving Machine With Uncoiling Speed 0 - 15m/min

Main Specifications

Active uncoiling, hydraulic to expand
Weight capacity: 5/7/10/15 Ton
Width of coil: 1500mm Max.
Inner diameter: 508-610mm
Outer diameter: 1300mm
Material of main shaft: 40Cr
Outline dimentision: about 3110x1650x1780mm
Hydraulic motor power: 2.5KW
Pneumatic damp pressing arm
Uncoiling speed: 0-15m/min
Capacity of hydraulic station: 40L
Hydraulic system pressure: 6.3Mpa
Coil car stoke: 2.5m
Pressure of hydraulic system:6.3Mpa
Weight of coil beared by car: 5-15 Ton

5 Ton Hydraulic Auto Decoiler / Uncoiler Curving Machine With Uncoiling Speed 0 - 15m/min 0

Our Advantages

High Quality
Reliable
Durable
Reasonable Price
Good after Service
1 Year Warranty
More Than 10 Years Experience

More Machine Pictures

5 Ton Hydraulic Auto Decoiler / Uncoiler Curving Machine With Uncoiling Speed 0 - 15m/min 1
