High Speed Hydraulic Auto Uncoiler / Decoiler with Weight Capacity Of 5 / 7 / 8 Ton

China High Speed Hydraulic Auto Uncoiler / Decoiler with Weight Capacity Of 5 / 7 / 8 Ton supplier
High Speed Hydraulic Auto Uncoiler / Decoiler with Weight Capacity Of 5 / 7 / 8 Ton supplier High Speed Hydraulic Auto Uncoiler / Decoiler with Weight Capacity Of 5 / 7 / 8 Ton supplier High Speed Hydraulic Auto Uncoiler / Decoiler with Weight Capacity Of 5 / 7 / 8 Ton supplier High Speed Hydraulic Auto Uncoiler / Decoiler with Weight Capacity Of 5 / 7 / 8 Ton supplier

Large Image :  High Speed Hydraulic Auto Uncoiler / Decoiler with Weight Capacity Of 5 / 7 / 8 Ton

Product Details:

Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-DECOILER

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Contact Now
Detailed Product Description
Decoiler Type: Hydraulic Decoiler / Uncoiler Weight Capacity: 5/7/10/8T
Uncoiling Speed: 0-15m/min Coil Width: Max. 1500mm
Electric Condition: 380V/3Phase/ 50HZ Pressure Of Hydraulic System: 6.3Mpa

High Speed Hydraulic Auto Uncoiler / Decoiler with Weight Capacity Of 5 / 7 / 8 Ton





   Description



Decoilers also known as uncoilers, are designed and engineered by Machinery for supporting coil and a smooth efficient unreeling of coil material into a roll forming production line with a load capacity from 3 Ton up to 15 ton. According to the power supply difference, there are manual version, motor version, and hydraulic version.





  Main Specifications



  • Active uncoiling, hydraulic to expand
  • Weight capacity: 5/7/10/15 Ton
  • Width of coil: 1500mm Max.
  • Inner diameter: 508-610mm
  • Outer diameter: 1300mm
  • Material of main shaft: 40Cr
  • Outline dimentision: about 3110x1650x1780mm
  • Hydraulic motor power: 2.5KW
  • Pneumatic damp pressing arm
  • Uncoiling speed: 0-15m/min
  • Capacity of hydraulic station: 40L
  • Hydraulic system pressure: 6.3Mpa
  • Coil car stoke: 2.5m
  • Pressure of hydraulic system:6.3Mpa
  • Weight of coil beared by car: 5-15 Ton





High Speed Hydraulic Auto Uncoiler / Decoiler with Weight Capacity Of 5 / 7 / 8 Ton







  Our Advantages



  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience
