Top Hat Channel / Furring Channel Roof Panel Roll Forming Machine

Top Hat Channel / Furring Channel Roof Panel Roll Forming Machine

   A). Main Specification

1. Material: GI, Carbon steel
2. Material thickness: 1.5-3.0mm
3. Main power: 15KW
4. Machine diameter: about 11500x1500x1300mm ( LXWXH )
5. Weight of machine: about 10 Ton
6. Main Technical Specification:
7. Decoiler: Manual or hydraulic decoiler ( customer can choose )
8. Weight capacity of decoiler: 5 Ton
9. Forming station: 18
10. Principle axis: 75mm diameter
11. Forming speed: 0-15m/min
12. Drive type: 1.5' chain transmission
13. Roller material: GCr15 steel, quenched and heated process
14. Main power: 15KW
15. Hydraulic power: 7.5KW
16. Electrical Control: PLC Frequency Control System with touch screen
17. PLC: PANASONIC Brand
18. Encoder: OMRON Brand
19. Transducer: PANASONIC Brand
20.

   B). Main Components

1.      Decoiler ----------------------------------------------- 1 Unit
2.      Feeding & Leveling -------------------------------- 1 Unit
3.      Main roll forming machine ------------------------ 1 Unit
4.      Hydraulic cutting device --------------------------- 1 Unit
5.      Hydraulic Station ------------------------------------ 1 Unit
6.      PLC computer control ------------------------------ 1 Unit
7.      Output table ------------------------------------------- 1 Unit

   C). Working Flow

Decoiler --- Fedding & Leveling --- Roll Forming --- Cut-to-length --- Run out table

   D). Application

        Metal angle, steel angle, angle steel, l section, wall angle, l shape, l profile

   E). Competitive  Advantages

         Best Design Oriented for Your Special Requirements

         High Quality

       Reasonable Price

       Good after Service

       1 Year Warranty

       More Than 10 Years Experience

   F). Reference Pictures
