Hydraulic Plate Rolling 4KW Main Power Z Purlin Roll Forming Machine

Hydraulic Plate Rolling 4KW Main Power Z Purlin Roll Forming Machine

   A). Main Components

1. Decoiler ---------------------------------------------- 1 Unit
2. Feeding ---------------------------------------------- 1 Unit
3. Main roll forming machine ---------------------- 1 Unit
4. Hydraulic punching device ---------------------- 1 Unit
5. Hydraulic cutting device -------------------------- 1 Unit
6. Hydraulic Station ----------------------------------- 1 Unit
7. PLC computer control ---------------------------- 1 Unit
8. Output table ----------------------------------------- 1 Unit

   B).  Main Speclications

1. Material: G.i Coil
2. Material Thickness:0.4-1.0mm
3. Main Power: 4KW
4. Hydraulic power: 4KW
5. Forming Station: about 10 steps ( adopt Italy Technology )
6. Axis Diameter: ¢ 70 mm
7. Forming Speed: 0-15m/min
8.  Forming Frame Structure: Guiding Column + Slide Blocks;
9. This forming frame structure design is much high precision than wall plate welding structure
10. PLC Brand: PANASONIC Brand
11. Machine Diameter: about 7000mm(L)x800mm(W)x1300mm (H)
12. Weight of machine: about 4 Ton
13. Voltage: 380V, 3 Phase 50Hz ( or depend on customer’s requirement )

   C). Applications

Metal stud and track, steel stud and track, c stud, u runner, u track, furring channel, roof ceiling batten, roof truss, c truss, light weight steel truss...

   D). Competitive Advantages

High Quality

Reasonable Price

Good after Service

1 Year Warranty

More Than 10 Years Experience

   E). More Pictures
