6.3Mpa Cold Roll Forming Machine , Automatical Hydraulic Decoiler With 0-15m/min Forming Speed

Name: 6.3Mpa Cold Roll Forming Machine , Automatical Hydraulic Decoiler With 0-15m/min Forming Speed
Brand: TECHWELL
SKU: TW-DECOILER
Price: 1.00 USD
Availability: InStock
Rating: 4.9 (171 reviews)

Large Image : 6.3Mpa Cold Roll Forming Machine , Automatical Hydraulic Decoiler With 0-15m/min Forming Speed

Product Details:

Place of Origin:	China
Brand Name:	TECHWELL
Certification:	CE
Model Number:	TW-DECOILER

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Contact Us
Packaging Details:	Standard packing
Delivery Time:	55-65 working days
Payment Terms:	40% T/T in advance, 60% T/T before shipment
Supply Ability:	20 sets

Contact Now

Detailed Product Description

Suitable Coil I.D:	508-610mm	Outer Diameter:	1300mm
Uncoiling Speed:	0-15m/min	Hydraulic Motor Power:	2.5KW
Weight Of Coil By Car:	10Ton	Pressure Of Hydraulic System:	6.3Mpa
High Light:	Roll Former Machine , Roll Forming Equipment

6.3Mpa Pressure Of Hydraulic System Automatical / HydraulicDecoiler With 0-15m/min Forming Speed

Introduction of Automatical / Hydraulic Decoiler

A material handling machine located at the beginning of a process line used to hold and safely pay off or uncoil the steel strip. It controls the speed and direction of the strip of metal as it unwinds from the coil and is sent to the line for processing, such as slitting or tube mill entry.

Main Specifications of Automatical / Hydraulic Decoiler

Active uncoiling, hydraulic to expand
Weight capacity: 5/7/10/15 Ton
Width of coil: 1500mm Max.
Inner diameter: 508-610mm
Outer diameter: 1300mm
Material of main shaft: 40Cr
Outline dimentision: about 3110x1650x1780mm
Hydraulic motor power: 2.5KW
Pneumatic damp pressing arm
Uncoiling speed: 0-15m/min
Capacity of hydraulic station: 40L
Hydraulic system pressure: 6.3Mpa
Coil car stoke: 2.5m
Pressure of hydraulic system:6.3Mpa
Weight of coil beared by car: 5-15 Ton
Electrica condition 380V / 3Phase / 50HZ

6.3Mpa Cold Roll Forming Machine , Automatical Hydraulic Decoiler With 0-15m/min Forming Speed 0

Feature of Automatical or Hydraulic Decoiler

It can work together with straighener. Buyer can also choose non motive power style

Uipped with heavy-duty roll bearings for best durability

Efficient automatic material feeding equipment, economy and practically

Can be provided with optional single speed or variable speed driving motor Machine

Competitive Advantages

1. Durable and widely used products

2.Simple to operate when assemble

3.Direct manufacturer, provide with high quality and best price.

4.Provide sample in free.

5.Products and design solution supplied fast and freely

6.Best design oriented for your special requirements

More Reference Machine Pictures

6.3Mpa Cold Roll Forming Machine , Automatical Hydraulic Decoiler With 0-15m/min Forming Speed 1

Our Factory Pictures

6.3Mpa Cold Roll Forming Machine , Automatical Hydraulic Decoiler With 0-15m/min Forming Speed 2

6.3Mpa Cold Roll Forming Machine , Automatical Hydraulic Decoiler With 0-15m/min Forming Speed 3
