0-15m/Min Forming Speed Downpipe Machine, Rainspout Roll Forming Machine With Coil Thickness 0.4-0.6mm

China 0-15m/Min Forming Speed Downpipe Machine, Rainspout Roll Forming Machine With Coil Thickness 0.4-0.6mm supplier
0-15m/Min Forming Speed Downpipe Machine, Rainspout Roll Forming Machine With Coil Thickness 0.4-0.6mm supplier 0-15m/Min Forming Speed Downpipe Machine, Rainspout Roll Forming Machine With Coil Thickness 0.4-0.6mm supplier 0-15m/Min Forming Speed Downpipe Machine, Rainspout Roll Forming Machine With Coil Thickness 0.4-0.6mm supplier 0-15m/Min Forming Speed Downpipe Machine, Rainspout Roll Forming Machine With Coil Thickness 0.4-0.6mm supplier

Large Image :  0-15m/Min Forming Speed Downpipe Machine, Rainspout Roll Forming Machine With Coil Thickness 0.4-0.6mm

Product Details:

Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-DP100

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 70-80 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 Sets
Contact Now
Detailed Product Description
Raw Material: Colored Steel Plate Or Aluminium Plate Coil Thickness: 0.4-0.6mm
Forming Speed: 6-15m/min Main Roller Stations: 20 Stations
Control System: Panasonic PLC Control, Frequency Converter, Encoder Etc Cutting: Hydraulic Cutting Automatically According To Required Length

0-15m/Min Forming Speed Downpipe Machine, Rainspout Roll Forming Machine With Coil Thickness 0.4-0.6mm



   Description of Downpipe Machine





1. One roll forming machine only can produce one pofile.



2. Downspout roll forming machine mainly consists of manual decoiler, pinch feeding, roll forming sysem, cutting equipment, protective guard, hydraulic system, PLC control system, dowmpipe elbow making machine and product supporter table.



3. Curving pipe forming machine as the auxiliary equipment for downspout roll forming machine, mainly consists of decoiler, roll forming system, cutting equipment, hydraulic system, PLC control system and out-put table.





   Main Specifications



  1. ​Material Thickness: 0.4-0.8mm
  2. Decoiler: Manual or hydraulic decoiler
  3. Weight capacity of decoiler: 3T
  4. Main motor power: 7.5Kw
  5. Forming stations: about 20 stations
  6. Forming speed: 0-15m/min
  7. Machine weight: about 12T
  8. Machine frame by 350H Beam welding
  9. Machine structure: wall board panel
  10. Axis diameter: 70mm
  11. Drive: Chain transmission
  12. Roller material: 45# forge steel, polished and coated with 0.05mm hard chrome surface
  13. Axis material: High grade 45# steel
  14. Cutting: Hydraulic cutting
  15. Hydraulic power: 5.5Kw
  16. PLC: PANASONIC Brand



   Reference Profile Drawing





0-15m/Min Forming Speed Downpipe Machine, Rainspout Roll Forming Machine With Coil Thickness 0.4-0.6mm

0-15m/Min Forming Speed Downpipe Machine, Rainspout Roll Forming Machine With Coil Thickness 0.4-0.6mm

0-15m/Min Forming Speed Downpipe Machine, Rainspout Roll Forming Machine With Coil Thickness 0.4-0.6mm







   Main Components



Decoiler 1 Unit
Feeding Guide 1 Unit
Downpipr Roll Forming Machine 1 Unit
Hydraulic Cutting 1 Unit
Hydraulic Station 1 Unit
PLC Computer Control 1 Unit
Output Table 1 Unit
Elbow Machine 1 Unit





   Working Flow





Decoiler--> Coil sheet guiding and feeding --> Roll forming machine with safty guard--> Tighten Device ->



Cut to length --> Out-put Table --> Curving machine



0-15m/Min Forming Speed Downpipe Machine, Rainspout Roll Forming Machine With Coil Thickness 0.4-0.6mm









   Applications



Rainwater downpipe, downspout, rainspout, water pipe, drainpipe



   Competitive Advantages



1. Durable and widely used products

2.Simple to operate when assemble

3.Direct manufacturer, provide with high quality and best price.

4.Provide sample in free.

5.Products and design solution supplied fast and freely

6.Best design oriented for your special requirements





   More Machine Reference Pictures



0-15m/Min Forming Speed Downpipe Machine, Rainspout Roll Forming Machine With Coil Thickness 0.4-0.6mm
