GCr15 Steel Roller Guide Rail Cold Roll Forming Machine With Chain Of Transmission, Hydraulic Cutting Device
Main Technical Parameters of Guide Rail Roll Former
| Coil Material | Galvanized steel, carbon steel |
| Material Thickness | 1.5-3.0mm |
| Decoiler Type | Manual or Hydraulic or Auto type |
| Coil I.D | 508-610mm |
| Forming Stations | About 16 stations (Depend on profiles) |
| Roller Material | GCr15 steel, surface coated with 0.05mm hard chrome |
| Axis of Diameter | 80mm |
| Shaft Material | High grade 45# steel |
| Drive Type | Chain drive |
| Forming Speed | 0-15m/min (Not including cutting) |
| Main Power | 15 KW |
| Punching Type | Hydraulic punching |
| Punching Mold Size | According to drawing |
| Cutting | Hydraulic cutting |
| Cutting Die Material | Cr12Mov |
| Cutting Tolerance | +/-1.5mm |
| PLC | Panasonic |
| Inverter | YASKAWA |
| Touch Screen | Panasonic |
| Operation Type | Touch screen & Button |
Working Flow Chart
Decoiler --- Feeding and Leveling --- Main Roll Forming --- Hydraulic Punching --- Cut-to-length ---
Run out Table
Main Components
Reference Profile Drawing
 |
|
|
Applications
Elevator guide rail, door frame guide rail, curtain track, shutter door slats guide
