Detailed Product Description
Raw Material: GI, Carbon Steel Forming Speed: 0-15m/min
Forming Stations: About 18 Stations Hydraulic Power: 7.5KW
Roller Material: GCr15 Steel, HRC58-62 Shaft Material: High Grade 45# Steel

0-15m/Min Forming Speed Hat Channel Cold Roll Forming Machine For Raw Material GI, Carbon Steel





   Main Technical Parameters of Hat Channel Roll Forming Machine



  • Thickness of sheet: 1.5-3.0mm
  • Coil width: Custom-made
  • Material: GI, Carbon steel
  • Decoiler / Uncoiler: Manual or hydraulic decoiler
  • Feeding rollers: 4 rollers
  • Leveling rollers: 7 rollers (upper 3 rollers, bottom 4 rollers)
  • Punching type: Hydraulic punching
  • Punching die: Cr12Mov, quenched, HRC58-62
  • Forming stations: 14 stations (Depend on profiles)
  • Roller material: GCr15 steel, HRC58-62
  • Diameter of shaft: 80mm
  • Shaft material: High grade 45# steel
  • Drive type: Chain transmission
  • Forming speed: 0-15m/min
  • Main power: 15KW
  • Hydraulic power: 7.5KW
  • Cutting type: Servo tracking cutting
  • Cutting tolerance: 10m+/-1.5mm
  • Encoder: OMRON Brand
  • PLC: PANASONIC Brand or Custom-made



   Description of Hat Channel Roll Former





 1. Metal steel hat channel have become a competitive and widely used product in the building industry giving a fire proof and easily erected system for partitioning and various other uses. The component parts of the system are ideal rollform applications.



 2. There are many kinds of profiles of the steel hat channel as the different market has the different requirements, we design and produce the forming machine according to clients’ drawings or samples normally.





   Main Components of Hat Channel Roll Former



  • Decoiler / Uncoiler--------------------------------------------------------------------------1 Unit
  • Pinch Feeding & Leveling-----------------------------------------------------------------1 Unit
  • Punching--------------------------------------------------------------------------------------1 Unit
  • Main Roll Forming Machine---------------------------------------------------------------1 Unit
  • Cutting to Length----------------------------------------------------------------------------1 Unit
  • Hydraulic Station-----------------------------------------------------------------------------1 Unit
  • PLC Computer Control Board-------------------------------------------------------------1 Unit
  • Runout Table---------------------------------------------------------------------------------1 Unit



   Flow Chart of Hat Channel



Manual Decoiler ---- Feeding guide & Leveling Device ---- Punching------Roll Forming ---- Cutting ------



Run out table





   Hat Channel Roll Former Reference Profile Drawing
